Siemens 3VA5220-5ED61-0AA0 200 Amp 2-Pole Molded Case Circuit Breaker – Feed-Thru Mount – 600V AC

In stock
SKU: 3VA5220-5ED61-0AA0 GTIN/UPC: 804766308352
$1,111.05
CONDITION
Need Reconditioned? Get Price by Calling
Call Us
Secure transaction
FREE & fast shipping on orders over $149
1 year warranty
30 day returns

Ask an expert

Email 866-972-6370

The Siemens 3VA5220-5ED61-0AA0 is a molded case circuit breaker (MCCB) from the SENTRON 3VA5 series, engineered for reliable protection in commercial and industrial electrical distribution systems. Built on the 3VA52 frame, this 200A, 2-pole breaker provides dependable long-time and instantaneous (LI) protection using a TM210 thermal-magnetic trip unit with fixed thermal and fixed magnetic settings. Designed with Medium (Class M) breaking capacity, it delivers interrupting performance up to 35kA at 480VAC and 18kA at 600VAC. The unit is intended for panelboard and switchboard applications and is supplied without lugs for flexible field termination.

Voltage and Rating

  • Current Rating: 200 Amps
  • Voltage Rating: 600 Volts AC
  • Phase: 1-Phase
  • Frequency: 50/60 Hz
  • AIC Rating:
    • 100kA @ 480VAC
    • 35kA @ 480VAC (Class M)
    • 18kA @ 600VAC

Key Specifications

  • Breaker Type: Molded Case Circuit Breaker (MCCB)
  • Series: SENTRON 3VA5
  • Family: 3VA
  • Part Number: 3VA5220-5ED61-0AA0
  • Frame Size: 3VA52 Frame
  • Number of Poles: 2-Pole
  • Mounting Style: Panel Mount / Feed-Thru
  • Trip Technology: Thermal Magnetic
  • Trip Unit: TM210
  • Trip Function: Long-Time and Instantaneous Protection (LI)
  • Trip Adjustability: Fixed Ir, Fixed Ii
  • Protection Type: Thermal Magnetic
  • Connection Configuration: Without Lugs

Technical Specifications

  • Breaking Capacity Class: Medium (Class M)
  • Application: Commercial and Industrial Power Distribution
  • Compatibility: Siemens 3VA Panelboards and Switchboards
  • Construction Features: HACR Rated, Reverse Feed, 2-Pole in 3-Pole Housing

Standards and Approvals

  • Certification: CSA Approved

Product Data

  • Manufacturer: Siemens
  • Series: SENTRON 3VA5
  • Part Number: 3VA5220-5ED61-0AA0

Dimensions and Weight

  • Height: 4.1 in
  • Width: 7.3 in
  • Depth: 4.2 in
  • Weight: 3.935 lb

Applications

  • Commercial Power Distribution Systems
  • Industrial Electrical Installations
  • Panelboards and Switchboards
  • Motor Control Centers
  • Feeder Circuit Protection
  • Branch Circuit Protection
  • Heavy Electrical Load Distribution
  • Retrofit and Upgrade Projects
  • Current-Limiting Protection Systems
  • High Fault Current Environments
  • Type Circuit Breakers
