Siemens 3VA6115-6HL31-0AA0 150 Amp 3-Pole Molded Case Circuit Breaker – Panel Mount – 240/480/600VAC Rated

The Siemens 3VA6115-6HL31-0AA0 is a high-performance molded case circuit breaker (MCCB) from the SENTRON 3VA6 series, designed for industrial and commercial power distribution systems requiring high interrupting capacity and precise electronic protection. Built on the 3VA61 frame, this 150A, 3-pole breaker provides reliable long-time and instantaneous (LI) protection through an electronic trip unit with adjustable settings. It is engineered for seamless integration into Siemens P2, P3, P4, and P5 panelboards, switchboards, and motor control centers. With a high fault interruption rating of up to 65kA at 480VAC, it ensures dependable protection in demanding electrical environments.

Voltage and Rating

• Current Rating: 150 Amps
• Voltage Rating: 240VAC, 480Y/277VAC, 480VAC, 600Y/347VAC, 600VAC
• Phase: 3-Phase
• Frequency: 50/60 Hz
• AIC Rating:
  • 100kA @ 240VAC
  • 65kA @ 480Y/277VAC
  • 65kA @ 480VAC
  • 22kA @ 600Y/347VAC
  • 22kA @ 600VAC

Key Specifications

• Breaker Type: Molded Case Circuit Breaker (MCCB)
• Series: SENTRON 3VA6
• Family: 3VA
• Part Number: 3VA6115-6HL31-0AA0
• Frame Size: 3VA61 Frame
• Number of Poles: 3-Pole
• Mounting Style: Panel Mount
• Terminal Type: Lugs (not included where specified)
• Trip Technology: Electronic Trip Unit
• Trip Function Code: LI
• Trip Function: Long-Time and Instantaneous Protection
• Trip Adjustability: Adjustable
• Protection Type: Electronic
• Connection Configuration: Lugs not included (as specified)

Technical Specifications

• Breaking Capacity Class: High interrupting capacity (Class H)
• Application: Industrial and Commercial Power Distribution
• Compatibility: Siemens P2, P3, P4, P5 Panelboards, Switchboards, Motor Control Centers
• Construction Features: HACR Rated, Current Limiting, Reverse Feed

Standards and Approvals

• Standards: IEC 60947-2, UL 489, CSA C22.2 No. 5
• Approvals: CE, CSA, UL

Product Data

• Manufacturer: Siemens
• Series: SENTRON 3VA6
• Part Number: 3VA6115-6HL31-0AA0

Applications

• Industrial Power Distribution Systems
• Commercial Electrical Installations
• Panelboards and Switchboards
• Motor Control Centers
• Feeder Circuit Protection
• Branch Circuit Protection
• High Fault Current Applications
• Critical Infrastructure Systems
• Precision Electronic Protection Systems
• Industrial Automation Systems
• Current-Limiting Protection Networks
