Siemens 3VA6325-6HN31-0AA0 250 Amp 3-Pole Molded Case Circuit Breaker – Feed-Thru – Electronic Trip Unit – 240/480/600VAC Rated

In stock
SKU: 3VA6325-6HN31-0AA0 GTIN/UPC: 804766314384
$3,018.79
CONDITION
Need Reconditioned? Get Price by Calling
Call Us
Secure transaction
FREE & fast shipping on orders over $149
1 year warranty
30 day returns

Ask an expert

Email 866-972-6370

The Siemens 3VA6325-6HN31-0AA0 is a molded case circuit breaker (MCCB) from the SENTRON 3VA6 series, designed for industrial and commercial power distribution systems requiring high-performance protection and coordination. Built on the 3VA63 frame, this 250A, 3-pole breaker provides advanced protection using an ETU350 electronic trip unit with LSI (Long-Time, Short-Time, and Instantaneous) functionality. It is suitable for feeder and distribution applications in Siemens panelboards, switchboards, and motor control centers. With high interrupting capability up to 65kA at 480VAC, it delivers reliable protection in medium-to-high fault current environments.

Voltage and Rating

  • Current Rating: 250 Amps
  • Voltage Rating: 240VAC, 480VAC, 600VAC
  • Phase: 3-Phase
  • Frequency: 50/60 Hz
  • AIC Rating:
    • 100kA @ 240VAC
    • 65kA @ 480VAC
    • 22kA @ 600VAC

Key Specifications

  • Breaker Type: Molded Case Circuit Breaker (MCCB)
  • Series: SENTRON 3VA6
  • Family: 3VA
  • Part Number: 3VA6325-6HN31-0AA0
  • Frame Size: 3VA63 Frame
  • Number of Poles: 3-Pole
  • Connection Type: Feed-Thru
  • Mounting Style: Panel Mount
  • Terminal Type: Lugs (not included where specified)
  • Trip Technology: Electronic Trip Unit
  • Trip Unit: ETU350
  • Functions: Long-Time, Short-Time, Instantaneous (LSI)
  • Protection Type: Electronic
  • Connection Configuration: Without Lugs (as specified)

Technical Specifications

  • Breaking Capacity Class: High interrupting capacity (Class H)
  • Application: Industrial and Commercial Power Distribution
  • Compatibility: Siemens 3VA Panelboards, Switchboards, Motor Control Centers
  • Construction Features: HACR Rated, Current Limiting, Reverse Feed

Standards and Approvals

  • Standards: IEC 60947-2, UL 489, CSA C22.2 No. 5
  • Approvals: CE, CSA, UL

Product Data

  • Manufacturer: Siemens
  • Series: SENTRON 3VA6
  • Part Number: 3VA6325-6HN31-0AA0

Applications

  • Industrial Power Distribution Systems
  • Commercial Electrical Installations
  • Panelboards and Switchboards
  • Motor Control Centers
  • Feeder Circuit Protection
  • Branch Circuit Protection
  • Selective Coordination Systems
  • High Fault Current Applications
  • Critical Infrastructure Systems
  • Heavy Electrical Load Distribution
  • Current-Limiting Protection Networks
  • Type Circuit Breakers
  • Vendor Siemens / ITE
  • Brand Siemens
