Siemens 3VA6460-5HL31-0AA0 600 Amp 3-Pole Molded Case Circuit Breaker – Panel Mount – 240/480/600VAC Rated

In stock
SKU: 3VA6460-5HL31-0AA0 GTIN/UPC: 804766316036
$3,636.01
CONDITION
Need Reconditioned? Get Price by Calling
Call Us
Secure transaction
FREE & fast shipping on orders over $149
1 year warranty
30 day returns

Ask an expert

Email 866-972-6370

The Siemens 3VA6460-5HL31-0AA0 is a high-performance molded case circuit breaker (MCCB) from the SENTRON 3VA6 series, designed for commercial and industrial power distribution systems requiring high reliability and protection. Built on the robust 3VA64 frame, this 600A, 3-pole breaker provides dependable long-time and instantaneous (LI) protection using an ETU320 electronic trip unit with adjustable settings for precise coordination and fault protection. It is suitable for installation in Siemens P4 and P5 panelboards, switchboards, and motor control centers, and supports reverse feed applications. With a high interrupting capacity of up to 35kA at 480VAC, it ensures stable operation in demanding electrical environments.

Voltage and Rating

  • Current Rating: 600 Amps
  • Voltage Rating: 240VAC, 480VAC, 600VAC
  • Phase: 3-Phase
  • Frequency: 50/60 Hz
  • AIC Rating:
    • 100kA @ 240VAC
    • 35kA @ 480VAC
    • 18kA @ 600VAC

Key Specifications

  • Breaker Type: Molded Case Circuit Breaker (MCCB)
  • Series: SENTRON 3VA6
  • Family: 3VA
  • Part Number: 3VA6460-5HL31-0AA0
  • Frame Size: 3VA64 Frame
  • Number of Poles: 3-Pole
  • Mounting Style: Panel Mount
  • Terminal Type: Lugs (not included where specified)
  • Trip Technology: Electronic Trip Unit
  • Trip Unit: ETU320
  • Trip Function Code: LI
  • Trip Function: Long-Time and Instantaneous Protection
  • Trip Adjustability: Adjustable
  • Protection Type: Electronic
  • Connection Configuration: Lugs not included (as specified)

Technical Specifications

  • Breaking Capacity Class: Class M
  • Application: Industrial and Commercial Power Distribution
  • Compatibility: Siemens P4, P5 Panelboards, Switchboards, Motor Control Centers
  • Construction Features: HACR Rated, Current Limiting, Reverse Feed

Standards and Approvals

  • Standards: IEC 60947-2, UL 489, CSA C22.2 No. 5
  • Approvals: CE, CSA, IEC, UL, VDE

Product Data

  • Manufacturer: Siemens
  • Series: SENTRON 3VA6
  • Part Number: 3VA6460-5HL31-0AA0

Applications

  • Industrial Power Distribution Systems
  • Commercial Electrical Installations
  • Motor Control Centers
  • Switchboards and Panelboards
  • Feeder Circuit Protection
  • Branch Circuit Protection
  • High Fault Current Applications
  • Critical Infrastructure Systems
  • Selective Coordination Systems
  • Reverse Feed Applications
  • Current-Limiting Protection Networks
  • Type Circuit Breakers
