Siemens / ITE

Siemens 3VA6460-6HN31-0AA0 600 Amp 3-Pole Molded Case Circuit Breaker – Panel Mount – 240/480/600VAC Rated

In stock
SKU: 3VA6460-6HN31-0AA0 GTIN/UPC: 804766315817
$3,210.56
CONDITION
Need Reconditioned? Get Price by Calling
Call Us
Secure transaction
FREE & fast shipping on orders over $149
1 year warranty
30 day returns

Ask an expert

Email 866-972-6370

The Siemens 3VA6460-6HN31-0AA0 is a high-performance molded case circuit breaker (MCCB) from the SENTRON 3VA6 series, designed for commercial, industrial, and infrastructure power distribution systems requiring high reliability and protection. Built on the 3VA64 frame, this 600A, 3-pole breaker provides dependable overcurrent protection using an ETU350 electronic trip unit with adjustable long-time, short-time, and instantaneous (LSI) functions for coordinated system protection. It is engineered for installation in Siemens panelboards, switchboards, and motor control centers. With a high interrupting capacity of up to 65kA at 480VAC, it ensures safe operation in high fault-current environments.

Voltage and Rating

  • Current Rating: 600 Amps
  • Voltage Rating: 240VAC, 480VAC, 600VAC
  • Phase: 3-Phase
  • Frequency: 50/60 Hz
  • AIC Rating:
    • 100kA @ 240VAC
    • 65kA @ 480VAC
    • 22kA @ 600VAC

Key Specifications

  • Breaker Type: Molded Case Circuit Breaker (MCCB)
  • Series: SENTRON 3VA6
  • Family: 3VA
  • Part Number: 3VA6460-6HN31-0AA0
  • Frame Size: 3VA64 Frame
  • Number of Poles: 3-Pole
  • Mounting Style: Panel Mount
  • Terminal Type: Lugs (not included where specified)
  • Trip Technology: Electronic Trip Unit
  • Trip Unit: ETU350
  • Trip Function Code: LSI
  • Trip Function: Long-Time, Short-Time, and Instantaneous Protection
  • Trip Adjustability: Adjustable
  • Protection Type: Electronic
  • Connection Configuration: Lugs not included (as specified)

Technical Specifications

  • Breaking Capacity Class: High interrupting capacity (Class H)
  • Application: Industrial, Commercial, and Infrastructure Power Distribution
  • Compatibility: Siemens Panelboards, Switchboards, Motor Control Centers
  • Construction Features: HACR Rated, Current Limiting, Reverse Feed

Standards and Approvals

  • Standards: IEC 60947-2, UL 489, CSA C22.2 No. 5
  • Approvals: CE, CSA, UL

Product Data

  • Manufacturer: Siemens
  • Series: SENTRON 3VA6
  • Part Number: 3VA6460-6HN31-0AA0

Applications

  • Industrial Power Distribution Systems
  • Commercial Electrical Installations
  • Infrastructure and Utility Systems
  • Motor Control Centers
  • Switchboards and Panelboards
  • Feeder Circuit Protection
  • Branch Circuit Protection
  • High Fault Current Applications
  • Critical Infrastructure Systems
  • Selective Coordination Systems
  • Current-Limiting Protection Networks
  • Type Circuit Breakers
  • Vendor Siemens / ITE
  • Brand Siemens
