Siemens B2125HH Molded Case Circuit Breaker | 125A, 2-Pole, 240V

The Siemens B2125HH is a 2-pole, 125 Amp, 240 V AC molded case circuit breaker designed for heavy-duty residential and light commercial applications. As a high-interrupting variant within the BL-frame family, this breaker is engineered to provide superior protection for high-load circuits, such as sub-panel feeders, large HVAC systems, and industrial machinery.

The "HH" suffix denotes a high-interrupting capacity of 65 kAIC @ 240 V AC, making it suitable for installations near the service entrance or in environments where high fault currents are possible. It features a bolt-on mounting style for secure installation in Siemens P1, P2, and P3 panelboards.

Key Features

• Poles: 2

• Amperage: 125 A

• Voltage: 240 V AC

• Type: Molded Case Circuit Breaker (Type BLH/BHH)

• Trip Unit: Fixed Thermal-Magnetic

• Interrupting Capacity: 65 kAIC @ 240 V AC

• Mounting Style: Bolt-On

• Applications: Main or branch protection in Siemens panelboards, HVAC systems, and heavy residential loads

• Protection: Reliable protection against sustained thermal overloads and high-energy short circuits

Technical Specifications

• Manufacturer: Siemens

• Catalog Number: B2125HH

• UPC Number: 783643263598

• Phase: Single-phase

• Frequency Rating: 60 Hz

• Connection: Bolt-On

• Wire Range: #4 AWG - 2/0 AWG (Cu/Al)

• Approvals: UL Listed, CSA Certified, HACR Rated
