Siemens BG220 Molded Case Circuit Breaker – BG Series – 20A – 2 Pole – 120V – Switching Neutral – 10kAIC – Bolt-On

The Siemens BG220 is a BG Series molded case circuit breaker designed for specialized 120VAC applications requiring switching neutral functionality. This 20A, two-pole breaker disconnects both the hot and neutral conductors during fault conditions, providing enhanced circuit isolation and safety. Featuring thermal magnetic trip technology with Long-Time and Instantaneous (LI) protection, it delivers reliable protection against overloads and short circuits.

The BG220 is designed for bolt-on installation in Siemens panelboards and serves as the direct replacement for the discontinued BG2B020 model, ensuring continued support for legacy electrical systems. Its common trip mechanism and HACR rating make it suitable for a wide range of commercial and industrial applications.

Specifications

• Brand: Siemens
• Series: BG
• Part Number: BG220
• Product Type: Molded Case Circuit Breaker
• Mounting Style: Bolt-On
• Terminal Type: Lugs

Electrical Ratings

• Current Rating: 20A
• Number of Poles: 2 Pole
• Voltage Rating: 120VAC
• Phase: 1 Phase
• Interrupting Capacity: 10kAIC @ 120VAC
• Protection Type: Thermal Magnetic
• Trip Function Code: LI
• Trip Functions: Long-Time, Instantaneous
• Trip Adjustability: Fixed

Technical Features

• Switching neutral design for complete circuit isolation
• Common trip mechanism
• Thermal magnetic protection technology
• HACR rated construction
• Direct replacement for BG2B020
• Bolt-on mounting for secure installation

Wiring Specifications

• Wire Range: 14–6 AWG Copper/Aluminum
• Maximum Wire Size: 6 AWG
• Minimum Wire Size: 14 AWG

Compatibility

• For Use With: Siemens Panelboards

Available Options & Accessories

• Shunt Trip
• Auxiliary Switch
• Alarm Switch
• Load Side Lugs

Standards and Approvals

• UL 489
• CSA C22.2 No. 5
• CSA Approved
• UL Listed
• HACR Rated

Environmental Specifications

• Ambient Temperature Rating: 40°C

Applications

• Specialized 120VAC circuits
• Commercial electrical distribution systems
• Industrial control panels
• HVAC equipment circuits
• Branch circuit protection
• Applications requiring switched neutral protection
• Legacy Siemens panelboard installations
