Siemens ED63B020 Molded Case Circuit Breaker – Sentron Series – ED Frame – 20A – 3 Pole – 600V – Feed-Thru – 25kAIC

The Siemens ED63B020 is a Sentron Series molded case circuit breaker designed for dependable overcurrent protection in commercial and industrial three-phase electrical distribution systems. This 20A, three-pole breaker operates at 600V and features a feed-thru connection design with line and load-side lug terminals for flexible installation and wiring convenience.

Built on Siemens’ ED frame platform, the ED63B020 uses thermal magnetic trip technology to provide reliable Long-Time and Instantaneous (LI) protection against overloads and short-circuit faults. Its 25kA interrupting capacity at 480V ensures strong fault protection for demanding electrical environments.

Specifications

• Brand: Siemens
• Manufacturer: Siemens Breakers
• Part Number: ED63B020
• Series: Sentron Series
• Type: ED Frame
• Category: Molded Case Circuit Breaker
• Connection Type: Feed-Thru

Electrical Ratings

• Current Rating: 20A
• Number of Poles: 3 Pole
• Voltage Rating: 600V AC
• Phase: 3 Phase
• Interrupting Capacity: 25kAIC @ 480V
• Protection Type: Thermal Magnetic
• Trip Functions: Long-Time, Instantaneous (LI)

Technical Features

• Feed-thru design with line & load-side lug terminals
• Thermal magnetic overcurrent protection system
• Long-Time and Instantaneous trip functions
• High interrupting capacity for industrial applications
• Suitable for three-phase power distribution
• ED frame construction for panelboard installation

Environmental & Mechanical

• Ambient Temperature Rating: 40°C
• Dimensions (H × W × D): 6.35" × 3" × 3.92"
• Weight: 3.77 lbs

Standards and Approvals

• CSA Approved
• Siemens Sentron Series Authentic Product

Applications

• Industrial power distribution systems
• Commercial electrical panels
• Three-phase branch and feeder circuits
• Motor and equipment protection
• Manufacturing and processing facilities
• High-voltage distribution systems
