Siemens HED43B060L 60A 3-Pole 480V Sentron ED Frame Molded Case Circuit Breaker Thermal Magnetic 42kA@480V

Product Description

The Siemens HED43B060L is a 60 Amp, 3-Pole thermal magnetic molded case circuit breaker designed for commercial and industrial power distribution systems. Part of Siemens' Sentron ED Frame family, this breaker provides dependable overload and short-circuit protection while featuring factory-installed line and load lugs for simplified installation in panelboards, switchboards, and OEM equipment.

Key Features

• Catalog Number: HED43B060L
• Manufacturer: Siemens
• Amperage: 60 Amp
• Poles: 3-Pole
• Voltage Rating: 480VAC
• ED Frame Circuit Breaker
• Thermal Magnetic Trip Unit
• Factory Installed Line & Load Lugs
• Bolt-On Mounting
• Compact Design
• UL 489 Listed
• CSA Certified

Interrupting Ratings (KAIC)

• 65kA @ 240VAC
• 42kA @ 480VAC

Technical Specifications

• Manufacturer: Siemens
• Catalog Number: HED43B060L
• Series: Sentron ED Frame
• Frame Size: ED
• Type: Molded Case Circuit Breaker
• Amperage: 60A
• Poles: 3
• Voltage Rating: 480VAC
• Frequency: 50/60 Hz
• Trip Unit: Thermal Magnetic
• Mounting Style: Bolt-On
• Connection Type: Factory Installed Line & Load Lugs
• Protection Functions:
  • Long-Time Protection
  • Instantaneous Protection
• Certifications:
  • UL 489 Listed
  • CSA Certified

Product Data

• Brand: Siemens
• Manufacturer: Siemens
• Model: HED43B060L
• Series: Sentron ED Frame
• Type: Molded Case Circuit Breaker
• Frame Size: ED
• Protection Type: Thermal Magnetic
• Mounting: Bolt-On
• Connection: Factory Installed Line & Load Lugs
• Condition: New / Reconditioned
• Phase: 3 Phase
• Rated Current: 60A
• Rated Voltage: 480VAC
• UPC: 783087018338
• GTIN: 00783087018338
• Dimensions:
  • Height: 6.50 in
  • Width: 4.13 in
  • Depth: 3.93 in
• Weight: Approximately 4 lbs
• Country of Manufacture: United States

Compatible Equipment

• Siemens Panelboards
• Siemens Switchboards
• Siemens Sentron Distribution Equipment
• OEM Power Distribution Assemblies Utilizing ED Frame Breakers

Applications

• Commercial Buildings
• Industrial Facilities
• Manufacturing Equipment
• Power Distribution Systems
• OEM Electrical Equipment
• Motor Circuit Protection

Replacement Information

• Siemens ED Frame Circuit Breaker
• Direct replacement should match catalog number HED43B060L
• Thermal Magnetic Fixed Trip Configuration
• Factory Installed Line and Load Lugs Included
• Bolt-On Mounting Configuration

Note: The "L" suffix indicates factory-installed line and load lugs. The HED43B060L is the lug version of the HED43B060 and should be matched accordingly when replacing an existing breaker.
