Siemens HLXD63B600 Molded Case Circuit Breaker – Sentron Series – 600A – 3 Pole – 600V – Bolt-On – Thermal Magnetic – High Interrupting Capacity

The Siemens HLXD63B600 is a Sentron Series molded case circuit breaker designed for heavy-duty industrial and commercial power distribution systems. Rated at 600A and 600V AC, this 3-pole breaker provides reliable circuit protection using a thermal-magnetic trip unit with long-time overload and instantaneous short-circuit protection for safe and stable operation under demanding electrical conditions.

Built for high fault current environments, the HLXD63B600 delivers a high interrupting capacity of 65kA at 480V. Its bolt-on mounting design, compact Sentron HLXD frame construction, and non-interchangeable trip unit ensure durability, safety, and consistent performance in critical power distribution applications.

Specifications

• Brand: Siemens Breakers
• Part Number: HLXD63B600
• Series: Sentron Series
• Type: HLXD Frame Molded Case Circuit Breaker
• Category: Molded Case Circuit Breaker / 3-Pole
• Connection Type: Bolt-On
• Trip Technology: Thermal Magnetic
• Trip Function: LI (Long-Time and Instantaneous)

Electrical Ratings

• Current Rating: 600A
• Voltage Rating: 600V AC
• Number of Poles: 3 Pole
• Phase: 3 Phase

Interrupting Capacity

• 65kA @ 480V

Construction

• Sentron HLXD frame design
• Bolt-on mounting configuration
• Non-interchangeable trip unit
• Rated for operation at 40°C
• Industrial-grade molded case construction

Connections

• Lugs not included
• Field termination required
• Suitable for panelboard and switchboard applications

Physical Specifications

• Dimensions (H × W × D): 7.5" × 11" × 4"
• Weight: 18.15 lbs

Functions

• LI – Long-Time and Instantaneous Protection
• Thermal-magnetic trip system
• High interrupting capacity design

Standards and Approvals

• CSA Approved

Applications

• Industrial power distribution systems
• Commercial switchboards and panelboards
• Large feeder and main circuit protection
• Heavy-load electrical systems
• Critical infrastructure distribution
• High fault current environments
