Siemens / ITE ED63B080 80A 3 Pole MCCB – Bolt On – 600V

In stock
SKU: ED63B080-NS GTIN/UPC: 783643209763
$699.00
Condition
Secure transaction
FREE & fast shipping on orders over $149
1 year warranty
30 day returns

Ask an expert

Email 866-972-6370

The Siemens / ITE ED63B080 is a durable molded case circuit breaker designed to provide reliable protection in industrial and commercial electrical systems. Featuring an 80A thermal magnetic non-interchangeable trip unit, it delivers dependable protection against overloads and short circuit faults. Built on the compact ED frame platform, this breaker offers consistent performance, operational reliability, and long service life. Its bolt-on mounting configuration ensures secure installation and efficient integration into power distribution systems.

Product Specification:

  • Manufacturer: Siemens / ITE
  • Model: ED63B080
  • Frame Type: ED Frame
  • Type: Molded Case Circuit Breaker (MCCB)
  • Amperage: 80A at 40°C
  • Poles: 3 Pole
  • Connection Type: Bolt On
  • Trip Unit: Thermal Magnetic Non-Interchangeable
  • Warranty: 1 Year

Technical Specification:

  • Interrupting Capacity: 65 kA @ 240VAC
  • Interrupting Capacity: 25 kA @ 480VAC
  • Interrupting Capacity: 18 kA @ 600VAC
  • Frequency: 50/60 Hz
  • Frame Style: ED
  • Operating Mechanism: Fixed MCCB with non-interchangeable trip unit

Voltage and Ratings:

  • Rated Voltage: 240VAC / 480VAC / 600VAC
  • Maximum Voltage: 600VAC
  • Rated Current: 80A
  • Interrupting Ratings: 65kA @ 240VAC, 25kA @ 480VAC, 18kA @ 600VAC

Product Data:

  • Product Type: Molded Case Circuit Breaker
  • Application: Industrial and Commercial Electrical Protection
  • Mounting Type: Bolt On
  • Configuration: 3 Pole System
  • Construction: Compact ED frame design
  • Accessories: Compatible with various circuit breaker accessories
  • Terminal Design: Standard Line and Load End Terminals
  • Warranty Support: 1-year in-house warranty for new and certified reconditioned units

Important Note:
This circuit breaker should be installed by a qualified electrician according to applicable electrical codes and system requirements. Improper installation or incorrect application may result in equipment damage or safety hazards. Always confirm system voltage, current rating, and interrupting capacity before installation and operation.
