Siemens JXD22B250 Circuit Breaker – Sentron Series – 250A – 2 Pole – 240VAC – Thermal Magnetic – Bolt-On

The Siemens JXD22B250 is a Sentron Series molded case circuit breaker designed to provide dependable overload and short-circuit protection for commercial, industrial, and power distribution applications. Rated at 250A and 240VAC, this 2-pole breaker is engineered for single-phase electrical systems requiring reliable protection and high-performance fault interruption.

Featuring a thermal-magnetic trip unit with Long-Time and Instantaneous (LI) protection functions, the JXD22B250 delivers effective protection against overload conditions and short-circuit faults. With a 65kA interrupting capacity at 240VAC, it is capable of safely clearing high fault currents, helping protect electrical equipment and maintain system reliability.

Built on the JD frame platform and rated for operation in 40°C ambient conditions, this breaker utilizes a secure bolt-on mounting design and comes complete with a factory-installed non-interchangeable trip unit. Lugs are not included, allowing flexibility in selecting appropriate terminal connections for specific installation requirements.

Specifications

• Brand: Siemens
• Part Number: JXD22B250
• Series: Sentron Series
• Type: JXD Molded Case Circuit Breaker
• Frame Type: JD Frame
• Category: Molded Case Circuit Breaker
• Mounting Type: Bolt-On
• Protection Type: Thermal Magnetic
• Trip Unit: Non-Interchangeable
• Ambient Rating: 40°C
• Special Features: Lugs Not Included

Electrical Ratings

• Current Rating: 250A
• Voltage Rating: 240VAC
• Number of Poles: 2 Pole
• Phase: 1 Phase
• Interrupting Capacity: 65kA @ 240VAC
• Trip Functions: LI – Long-Time and Instantaneous

Construction

• Heavy-duty molded case construction
• JD frame design
• Bolt-on mounting configuration
• Thermal-magnetic trip mechanism
• Factory-installed non-interchangeable trip unit
• Field-selectable lug configuration
• Durable industrial-grade housing

Functions

• Overload protection
• Short-circuit protection
• Long-time delay protection
• Instantaneous fault protection
• Circuit switching and isolation

Dimensions

• Width: 7.5 in
• Height: 11 in
• Depth: 4 in

Standards

• UL Listed

Applications

• Commercial electrical distribution systems
• Industrial power distribution equipment
• Panelboards and switchboards
• Equipment feeder protection
• Motor and machinery protection
• High fault-current installations
• Single-phase power distribution systems
