Siemens JXD22B400 Circuit Breaker – Sentron Series – 400A – 2 Pole – 240VAC – Thermal Magnetic – Bolt-On

The Siemens JXD22B400 is a Sentron Series molded case circuit breaker engineered to provide reliable overload and short-circuit protection for commercial, industrial, and power distribution applications. Rated at 400A and 240VAC, this 2-pole breaker is designed for single-phase electrical systems that require high-capacity circuit protection and dependable performance in demanding operating environments.

Equipped with a thermal-magnetic trip unit featuring Long-Time and Instantaneous (LI) protection functions, the JXD22B400 offers effective protection against sustained overload conditions and high-level fault currents. With a 65kA interrupting capacity at 240VAC, it can safely interrupt substantial short-circuit currents, helping protect electrical equipment and maintain system reliability.

Built on the Siemens JD frame platform and designed for operation in 40°C ambient environments, this breaker utilizes a secure bolt-on mounting configuration and is supplied with a factory-installed non-interchangeable trip unit. Lugs are not included, providing flexibility in selecting terminal connections that best suit the application.

Specifications

• Brand: Siemens / ITE
• Part Number: JXD22B400
• Series: Sentron Series
• Type: JXD Molded Case Circuit Breaker
• Frame Type: JD Frame
• Category: Molded Case Circuit Breaker
• Mounting Type: Bolt-On
• Protection Type: Thermal Magnetic
• Trip Unit: Non-Interchangeable
• Ambient Rating: 40°C
• Special Features: Lugs Not Included

Electrical Ratings

• Current Rating: 400A
• Voltage Rating: 240VAC
• Number of Poles: 2 Pole
• Phase: 1 Phase
• Interrupting Capacity: 65kA @ 240VAC
• Trip Functions: LI – Long-Time and Instantaneous

Construction

• Heavy-duty molded case construction
• JD frame design
• Bolt-on mounting configuration
• Thermal-magnetic trip mechanism
• Factory-installed non-interchangeable trip unit
• Field-selectable lug configuration
• Rugged industrial-grade housing
• Designed for demanding electrical distribution applications

Functions

• Overload protection
• Short-circuit protection
• Long-time delay protection
• Instantaneous fault protection
• Circuit switching and isolation

Dimensions

• Height: 11 in
• Width: 7.5 in
• Depth: 4 in
• Weight: 15.2 lbs

Standards

• CSA Approved

Applications

• Commercial electrical distribution systems
• Industrial power distribution equipment
• Panelboards and switchboards
• Equipment feeder protection
• Motor and machinery protection
• High fault-current installations
• Single-phase power distribution systems
