Siemens JXD62B250 Circuit Breaker – Sentron Series – 250A – 2 Pole – 600VAC – Thermal Magnetic – Feed-Thru

The Siemens JXD62B250 is a Sentron Series molded case circuit breaker designed to provide dependable overload and short-circuit protection for commercial, industrial, and power distribution applications. Rated at 250A and 600VAC, this 2-pole breaker is engineered for single-phase electrical systems requiring reliable protection and high-performance operation in demanding environments.

Equipped with a thermal-magnetic trip unit featuring Long-Time and Instantaneous (LI) protection functions, the JXD62B250 delivers effective protection against sustained overload conditions and high-level fault currents. The breaker offers multiple interrupting ratings, including 100kA at 240VAC, 35kA at 480VAC, and 25kA at 600VAC, providing dependable fault-clearing performance across a variety of voltage applications.

Built on the Siemens JXD frame platform and calibrated for operation in 40°C ambient environments, this breaker features a feed-thru connection design and comes complete with a factory-installed non-interchangeable trip unit as well as line- and load-side lug terminals for simplified installation and secure connections.

Specifications

• Brand: Siemens Breakers
• Part Number: JXD62B250
• Series: Sentron Series
• Type: JXD Molded Case Circuit Breaker
• Category: Molded Case Circuit Breaker
• Connection Type: Feed-Thru
• Protection Type: Thermal Magnetic
• Trip Unit: Non-Interchangeable
• Ambient Rating: 40°C
• Terminal Configuration: Line & Load Side Lug Terminals Included

Electrical Ratings

• Current Rating: 250A
• Voltage Rating: 600VAC
• Number of Poles: 2 Pole
• Phase: 1 Phase
• Interrupting Capacity: 100kA @ 240VAC
• Interrupting Capacity: 35kA @ 480VAC
• Interrupting Capacity: 25kA @ 600VAC
• Trip Functions: LI – Long-Time and Instantaneous

Construction

• Heavy-duty molded case construction
• Feed-thru connection configuration
• Thermal-magnetic trip mechanism
• Factory-installed non-interchangeable trip unit
• Line- and load-side lug terminals included
• Rugged industrial-grade housing
• Designed for high-voltage distribution applications

Functions

• Overload protection
• Short-circuit protection
• Long-time delay protection
• Instantaneous fault protection
• Circuit switching and isolation

Dimensions

• Height: 7 in
• Width: 9 in
• Depth: 13 in
• Weight: 17.5 lbs

Standards

• CSA Approved

Applications

• Commercial electrical distribution systems
• Industrial power distribution equipment
• Switchboards and panelboards
• Feeder circuit protection
• Equipment and machinery protection
• High-voltage electrical systems
• Single-phase power distribution applications
