Siemens Q3100 100A 3-Pole Thermal-Magnetic Circuit Breaker – Plug-In – 240V

The Siemens Q3100 100 Amp 3-pole thermal-magnetic circuit breaker is engineered for reliable overload and short-circuit protection in residential and light commercial electrical distribution systems. Built to the trusted QP/MP design, it installs easily into compatible Siemens loadcenters using a plug-in mounting configuration. The thermal-magnetic trip mechanism ensures fast, accurate protection, while UL 489 listing confirms compliance with rigorous safety standards. Ideal for three-phase applications requiring dependable circuit protection.

Voltage and Rating

• Current Rating: 100 Amps
• Voltage Rating: 240 Volts AC
• Interrupt Capacity: 10 kAIC
• Frequency: 50/60 Hz
• Number of Poles: 3-Pole

Key Specifications

• Circuit Breaker Type: QP/MP Thermal-Magnetic
• Mounting Type: Plug-In
• Application: Electrical distribution
• Trip Technology: Thermal Magnetic
• Compatible Loadcenters: Siemens residential loadcenters
• Certifications: UL 489 Listed

Technical Features

• Provides three-pole circuit protection
• Thermal element protects against overload conditions
• Magnetic trip provides instantaneous short-circuit response
• Plug-in design for quick installation
• Suitable for residential and light commercial panel applications

Product Data

• • Manufacturer: Siemens
  • Brand: Q
  • Model Number: Q3100
  • UPC: 783643148475
  • Dimensions: Height 1.969 in; Width 2.756 in; Depth 2.756 in
  • Weight: 1.918 lb
