The Siemens QF215A is a 2-pole GFCI circuit breaker designed to deliver reliable 15A ground-fault protection for 120/240V circuits. Built for Siemens QP, Murray MP, and compatible loadcenters, it features plug-on mounting and Class A 5 mA trip sensitivity to enhance personnel safety. With a 10 kAIC interrupt rating and thermal-magnetic protection, this breaker helps guard against overloads, short circuits, and ground faults in residential applications such as kitchens, bathrooms, garages, and outdoor circuits. This model is obsolete and is commonly replaced by the US2:Q215GF with equivalent performance and fit.
Electrical Ratings:
- Amperage: 15 Amps
- Poles: 2-Pole
- Voltage: 120/240 Volts AC
- Interrupt Rating: 10 kAIC
- Trip Sensitivity: 5 mA (Class A)
Key Specifications:
- Breaker Type: Ground-Fault Circuit Interrupter (GFCI)
- Mounting Mode: Plug-in
- Connections Terminals: Plug-on
- Wire Size: #14–4 AWG Cu/Al
- Tightening Torque: 25 lb-in
- Trip Type: Thermal-Magnetic
Dimensions & Weight:
- Height: 3.50 in (approx.)
- Width: 2.0 in
- Depth: 3.0 in (approx.)
- Weight: 0.992 lbs
Certifications:
-
UL Listed
Product Data:
- Manufacturer: Siemens
- Brand: Siemens
- Product Range: QP / QPF / QF
- Model Number: US2:QF215A
