Siemens QSPD2A065P 65kA 2P Surge Protective Device – Plug-In – 120/240V

the Siemens QSPD2A065P BoltShield surge protective device provides reliable 65 kA per phase protection for 120/240V systems in Siemens loadcenters. Featuring a 2-pole design, UL Type 1 rating, 20 kA I-nominal, and 200 kA short-circuit current rating, it safeguards residential electrical systems from surges. The device includes an audible alarm and pre-wired #14 AWG neutral/ground for easy plug-in installation, ensuring fast, effective surge protection.

Electrical Ratings

• Surge Current: 65 kA per phase
• Poles: 2-Pole
• Voltage Rating: 120/240 V AC
• I-nominal Rating: 20 kA
• Short Circuit Current Rating: 200 kA
• Maximum Continuous Operating Voltage (MCOV): 150 V
• Design & Construction
• Product Type: Surge Protective Device
• Mounting Mode: Plug-in
• Connections: Pre-wired #14 AWG neutral/ground
• Audible Alarm: Yes

Physical Specifications

• Height: 3.07 in
• Width: 1.98 in
• Depth: 2.57 in
• Weight: 0.64 lbs

Certifications

• UL 1449 Listed
• cUL

Manufacturer Info

• Manufacturer: Siemens
• Brand: Siemens
• Product Range: BoltShield
• Model Number: QSPD2A065P
• UPC: 804766954870
