Siemens SLVBH3650G Bus Plug – Sentron Low-Amp Series – 400A – 3 Phase – 600VAC – Fusible – Class R/H/K – 200kAIC – Heavy Duty Horizontal

The Siemens SLVBH3650G is a Sentron Low-Amp series heavy-duty fusible bus plug designed for Siemens SL busway systems. Manufactured by Siemens Breakers, it provides a high-capacity tap-off solution for industrial and commercial power distribution applications requiring robust performance and reliable protection.

This horizontal-oriented fusible switch is rated up to 400A and is suitable for demanding electrical environments. It supports Class R, H, and K fuses and offers high interrupting capacity for superior fault protection in critical distribution systems.

Specifications

• Brand: Siemens
• Manufacturer: Siemens Breakers
• Part Number: SLVBH3650G
• Series: Sentron Low-Amp (SLVBH)
• Category: Bus Plug / Fusible Switch
• Configuration: 3 Phase, 3 Wire
• Current Rating: 400A Max
• Voltage Rating: 600VAC
• Interrupting Capacity: 200kA @ 480V
• Type: Heavy Duty Fusible Bus Plug
• Orientation: Horizontal
• Enclosure Rating: IP40
• Grounding: Internal ground included
• Fuse Compatibility: Class R, H, K

Construction

• Heavy-duty industrial bus plug enclosure
• Horizontal mounting design
• Designed for Siemens Sentron SL busway systems
• Supports aluminum and copper busway integration
• Fusible protection with high-capacity switching mechanism
• Rugged construction for demanding environments

Dimensions & Weight

• Height: 20.866 in
• Width: 42.913 in
• Depth: 23.622 in
• Weight: 145.31 lb

Applications

• Industrial busway power distribution systems
• Heavy commercial electrical infrastructure
• Manufacturing plants and production facilities
• Data centers and large load distribution networks
• High-capacity tap-off connections from busway systems

Certifications & Approvals

• CSA Approved
• Designed for Siemens Sentron Low-Amp busway systems
• Suitable for UL-compliant electrical distribution installations
• High interrupting capacity for industrial fault conditions
