Siemens V7E3633R Disconnect Switch – Vacu-Break Series – 100A – 3 Pole – 600VAC – Panel Mount – Fusible – 200kAIC
Couldn't load pickup availability
Ask an expert
The Siemens V7E3633R is a Vacu-Break series panel-mounted disconnect switch designed for use in Siemens switchboards and panelboard systems. Manufactured by Siemens Breakers, it provides safe and reliable circuit isolation and branch protection in industrial and commercial power distribution applications.
This 3-pole, 100A disconnect switch is rated for 600VAC operation and features a fusible, dual/twin configuration for enhanced protection and flexibility. With a high interrupting rating, it is suitable for demanding electrical environments requiring dependable switching and fault protection performance.
Specifications
- Brand: Siemens
- Manufacturer: Siemens Breakers
- Part Number: V7E3633R
- Series: Vacu-Break
- Category: Disconnect Switch / Panels & Load Centers
- Configuration: 3 Phase, 3 Pole
- Current Rating: 100A
- Voltage Rating: 600VAC
- Mounting Type: Panel Mount
- Interrupting Capacity: 200kAIC @ 480V
- NEMA Rating: 1
- Fusibility: Fusible
- Configuration Type: Dual / Twin
Compatibility
- SB1 Switchboards
- SB2 Switchboards
- F1 Panelboards
- F2 Panelboards
- Clampmatic Systems
- Vacu-Break Series Panelboards
- Switchgear Distribution Systems
Construction
- Heavy-duty panel-mounted disconnect switch assembly
- Fusible protection design for branch circuits
- Designed for Vacu-Break series systems
- Industrial-grade enclosure compatibility
- Reliable mechanical switching mechanism
Applications
- Industrial power distribution systems
- Commercial switchboards and panelboards
- Branch circuit isolation and protection
- Motor and feeder disconnect applications
- Electrical distribution switchgear systems
Certifications & Approvals
- CSA Approved
- Designed for Siemens Vacu-Break UL-compliant systems
- Suitable for industrial and commercial electrical installations
- Type Switches
- Vendor Siemens / ITE
- Brand Siemens
