GE SKHA36AT0800 800 Amp Molded Case Circuit Breaker – 3 Pole – 600 V – 50 kA@480 V – Bolt-On – Spectra Series

The GE SKHA36AT0800 is an 800 Amp, 3-pole, 3-phase molded case circuit breaker from the GE Spectra RMS Series. It is rated for 600 V AC and features a digital RMS trip unit with Long-Time, Short-Time, and Instantaneous (LSI) protection functions. The breaker is designed for bolt-on mounting and provides approximately 50 kA interrupting capacity at 480 V for commercial and industrial power distribution applications.

Specifications

• Manufacturer: General Electric
• Brand: GE
• Product Type: Molded Case Circuit Breaker
• Series: Spectra RMS
• Catalog Number / MPN: SKHA36AT0800
• Primary Rating: 800 Amp
• Poles / Configuration: 3 Pole
• Phase: 3 Phase
• Voltage: 600 V AC
• Interrupting Rating: Approximately 50 kA @ 480 V
• Trip Type: Digital RMS Electronic
• Trip Functions: LSI – Long-Time, Short-Time, and Instantaneous
• Connection / Mounting: Bolt-On
• Dimensions (H × W × D): 15.5" × 8.25" × 5.5"

Part Numbers & Identification

• Manufacturer: General Electric
• Brand: GE
• Catalog Number: SKHA36AT0800
• Series: Spectra RMS
• Current Rating: 800 A
• Pole Count: 3 Pole
• Product Type: Digital RMS Molded Case Circuit Breaker
• Trip Functions: LSI – Long-Time, Short-Time, and Instantaneous
• UPC: 783164211740
• GTIN: 00783164211740

Compatibility

The GE SKHA36AT0800 is designed for compatible GE Spectra RMS molded case circuit breaker and electrical distribution applications. Verify the specific panelboard or switchboard, system voltage, mounting configuration, and breaker compatibility before installation.

Certifications

• UL Listed
• CSA Listed
