Square D 8536SBO2V08 Motor Starter – Class 8536 – Type S – 18A – 3 Pole – 208VAC Coil – Non-Reversing – Open Type
Couldn't load pickup availability
Ask an expert
The Square D 8536SBO2V08 is a Class 8536 Type S non-reversing magnetic motor starter designed for reliable starting and stopping of AC squirrel-cage motors. Manufactured by Schneider Electric under the Square D brand, it is commonly used in industrial and commercial motor control applications requiring dependable operation and overload-protected motor switching.
This 3-pole, 18A starter is rated for 600VAC power circuits and includes a 208VAC 60Hz control coil. It is designed as an open-type device for installation in motor control centers, electrical panels, and industrial enclosures.
Specifications
- Brand: Square D
- Manufacturer: Schneider Electric
- Part Number: 8536SBO2V08
- Series: Class 8536
- Type: SBO
- Category: Motor Starter
- Configuration: 3 Pole
- Phase: 3 Phase
- Current Rating: 18A
- Voltage Rating: 600VAC
- Coil Voltage: 208VAC, 60Hz
- Mounting Type: Open Type
- Operation Type: Non-Reversing
Motor Ratings
- Typically used for general-purpose 3-phase motor control (exact HP not specified in provided data)
Construction
- Heavy-duty electromagnetic motor starter
- Open-frame NEMA construction
- Replaceable coil design
- Designed for integration into motor control systems
- Industrial-grade switching and protection system
Dimensions & Weight
- Weight: 4.02 lb
- Dimensions: Not specified
Applications
- Industrial motor control systems
- HVAC equipment
- Pumps and compressors
- Conveyor systems
- Manufacturing and automation equipment
- General-purpose motor starting and stopping
Certifications & Approvals
- UL Listed
- CSA Approved
- Authentic Square D / Schneider Electric product
- Type Motor Starter
- Vendor Square D
- Brand Square D
