Square D 8903LXO20V02 Lighting Contactor – Class 8903 – Type LX – 2 Pole – 30A – 600VAC – 120VAC Coil – Mechanically Held – Open Type

The Square D 8903LXO20V02 is a Class 8903 multipole lighting contactor designed for reliable control of lighting and other electrical loads in commercial and industrial applications. Manufactured by Schneider Electric under the Square D brand, this mechanically held contactor provides energy-efficient operation by requiring control power only during switching.

This 2-pole, 30A contactor is rated for 600VAC operation and features a 110/120VAC control coil. Supplied in an open-type configuration, it is intended for installation within control panels, switchboards, or suitable enclosures.

Specifications

• Brand: Square D
• Manufacturer: Schneider Electric
• Part Number: 8903LXO20V02
• Series: Class 8903
• Type: LX
• Category: Lighting Contactor
• Configuration: 2 Pole
• Phase: 1 Phase
• Current Rating: 30A
• Voltage Rating: 600VAC
• Coil Voltage: 110/120VAC
• Operation Type: Mechanically Held
• Enclosure Type: Open Type

Construction

• Mechanically held operating mechanism for reduced energy consumption
• Heavy-duty lighting control contactor
• Open-frame design for panel mounting
• Industrial-grade contact system for long service life
• Designed for dependable switching of lighting and electrical loads

Weight

• 4.60 lb

Applications

• Commercial lighting control systems
• Industrial lighting circuits
• Building automation systems
• Energy management systems
• Sign lighting and display control
• General-purpose load switching

Certifications & Approvals

• UL Listed
• CSA Certified
• NEMA compliant when installed in a suitable enclosure
• Authentic Square D / Schneider Electric product
• Designed for Class 8903 lighting contactor systems
• Suitable for commercial and industrial lighting control applications
