Square D 9007C62B2 Limit Switch – Heavy Duty Plug-In – Rotary Lever – DPDT (2NO-2NC) – 600VAC – IP67

The Square D 9007C62B2 is a heavy-duty industrial limit switch designed for precise position detection and reliable control in automation and machinery systems. Manufactured by Schneider Electric under the Square D brand, it belongs to the robust 9007 series, widely used in demanding industrial environments requiring durable and accurate switching performance.

This plug-in limit switch features a metal rotary lever actuator with spring return and snap-action operation, providing dependable switching in both clockwise and counterclockwise motion applications. Its DPDT contact configuration (2NO-2NC) ensures flexible circuit control, making it suitable for complex automation and safety systems.

Specifications

• Part Number: 9007C62B2
• Manufacturer: Schneider Electric / Square D
• Series: 9007
• Category: Motor Controls / Industrial Limit Switch
• Type: Heavy Duty Plug-in Limit Switch
• Body Material: Die-cast zinc alloy
• Actuator Type: Metal rotary lever head
• Operation Type: Snap action, spring return
• Motion: Clockwise / Counterclockwise operation

Electrical Ratings

• Voltage Rating: 600VAC / 600VDC
• Current Rating: 10A AC / 1A DC
• Contact Configuration: DPDT (2NO + 2NC)
• Contact Material: Silver contacts
• Terminal Type: Screw clamp (22–12 AWG)
• Cable Entry: 1/2"-14 NPT threaded connection

Mechanical Performance

• Operating Force: 4 pound-inch
• Total Travel: 90°
• Pretravel: 10°
• Differential Travel: 4°
• Switch Action: Snap action with spring return

Environmental Ratings

• Operating Temperature: -20 to 185 °F
• NEMA Ratings: 1, 2, 4, 6, 6P, 12, 13
• IP Rating: IP65 / IP66 / IP67
• Seal Material: Neoprene

Dimensions

• Width: 1.54 in
• Height: 1.77 in
• Depth: 4.02 in
• Weight: Approx. 4 lb

Construction

• Rugged die-cast zinc alloy housing for industrial durability
• Sealed construction for protection against dust, oil, and water ingress
• Plug-in modular design for easy installation and replacement
• High-reliability silver contacts for long electrical life
• Metal rotary lever for versatile mechanical sensing

Applications

• Industrial automation systems
• Conveyor and material handling equipment
• Machine safety interlocks
• Rotary motion detection systems
• Heavy-duty OEM machinery
• Process control and position sensing

Certifications & Approvals

• UL Listed
• CSA Certified
• CE Compliant
• RoHS Compliant
• NEMA 1/2/4/6/6P/12/13 rated
• IP65/IP66/IP67 protection
• Authentic Square D / Schneider Electric product
