Square D BGA260404 Molded Case Circuit Breaker – PowerPacT B-Frame – 2 Pole – 40A – 600Y/347VAC – I-Line Plug-In – BC Phase Connection

The Square D BGA260404 is a PowerPacT B-Frame molded case circuit breaker engineered for reliable circuit protection in commercial and industrial power distribution systems. Manufactured by Schneider Electric under the Square D brand, this 2-pole breaker combines compact design, dependable thermal-magnetic protection, and high interrupting capacity for demanding electrical applications.

Rated at 40A and 600Y/347VAC, the BGA260404 features fixed thermal-magnetic trip protection with long-time and instantaneous (LI) functions to safeguard equipment against overloads and short circuits. Its I-Line plug-in mounting configuration allows for quick installation into compatible Square D I-Line panelboards and switchboards. The breaker is factory-configured with a BC phase connection and includes load-side mechanical lug terminals for secure field wiring.

With a 35kA interrupting rating at 480VAC, this breaker is designed to withstand high fault-current conditions while maintaining dependable operation in critical distribution systems.

Specifications

• Brand: Square D
• Manufacturer: Schneider Electric
• Part Number: BGA260404
• Series: PowerPacT B-Frame
• Type: Molded Case Circuit Breaker
• Configuration: 2 Pole
• Phase: 1 Phase
• Current Rating: 40A
• Voltage Rating: 600Y/347VAC
• Mounting Style: I-Line Plug-In
• Connection Type: Load Side Mechanical Lug Terminals
• Phase Connection: BC
• Trip Technology: Thermal Magnetic
• Trip Functions: LI – Long-Time and Instantaneous
• Interrupt Rating: 35kA @ 480VAC

Electrical Ratings

• Current Rating: 40A
• Voltage Rating: 600Y/347VAC
• Interrupting Capacity: 35kA @ 480VAC
• Continuous Current Rating: 80%
• Protection Type: Overload and Short-Circuit Protection

Dimensions

• Weight: 2.10 lb

Construction

• Compact PowerPacT B-Frame design
• Fixed thermal-magnetic trip unit
• Non-interchangeable trip mechanism
• Factory-configured BC phase connection
• I-Line style plug-in mounting for rapid installation
• Load-side mechanical lug terminals
• High interrupting capacity for demanding fault-current applications
• Durable molded case construction

Applications

• Commercial electrical distribution systems
• Industrial power distribution equipment
• I-Line panelboards
• I-Line switchboards
• Branch circuit protection
• Manufacturing facilities
• Institutional and commercial buildings

Certifications & Approvals

• CSA Approved
• UL Listed
• IEC Compliant
• NOM Compliant
• CE Marked
• Authentic Square D / Schneider Electric Product
• Designed for PowerPacT B-Frame Applications
