Square D EDB14020 20A 1-Pole Thermal-Magnetic Circuit Breaker – Bolt-On – 277V

The Square D EDB14020 20 Amp single-pole thermal-magnetic circuit breaker delivers reliable protection for NF panelboards in commercial and industrial applications. Designed for HID and switching-duty loads, it provides dependable short-circuit and overload protection. HACR certified and cULus/IEC approved, this bolt-on breaker features a trip indicator for easy local signaling and supports both copper and aluminum wiring, ensuring safe and durable operation.

Voltage and Rating

• Current Rating: 20 Amps
• Voltage Rating: 277 Volts AC
• Interrupting Capacity: 25 kA @ 120V AC, 18 kA @ 240V AC, 18 kA @ 277V AC
• Trip Unit Rating: 875A
• Holding Current: 270A

Key Specifications

• Breaker Type: E-Frame Thermal-Magnetic Circuit Breaker
• Number of Poles: 1-Pole
• Mounting Type: Bolt-On
• Application Rating: HID rated, Switching Duty rated, HACR certified
• Protection Type: Short-circuit, Overload
• Local Signaling: Trip indicator

Technical Specifications

• • Wire Compatibility: Copper 14–6 AWG, Aluminum 12–6 AWG
  • Tightening Torque: 30.09 lbf.in (3.4 N·m)
  • Operating Mechanism: Thermal-magnetic

Product Data

• Manufacturer: Schneider Electric
• Brand: EDB
• Model Number: EDB14020
• UPC: 785901878902
• Product Destination: NF panelboard
• Certifications: cULus, IEC

• Dimensions:

  • Height: 5.66 in
  • Width: 0.98 in
  • Depth: 4.05 in
  • Weight: 2 lb
