Square D EDB14025 Bolt-On Circuit Breaker – 1 Pole – 25A – 277VAC – EDB Series – Thermal Magnetic – HID/HACR Rated

The Square D EDB14025 is an E-Frame molded case circuit breaker from Schneider Electric designed for reliable branch circuit protection in Square D NF panelboards. It is commonly used in commercial lighting, HVAC, and general electrical distribution applications where HID and HACR ratings are required.

This 1-pole, bolt-on breaker provides secure installation and consistent electrical performance in panelboard environments. It uses a thermal-magnetic trip mechanism with LI (Long-Time and Instantaneous) protection, ensuring dependable response to overloads and short-circuit conditions.

Engineered for commercial 277V systems, the EDB14025 is suitable for lighting and building electrical loads requiring stable protection and straightforward installation.

Specifications

• Brand: Square D
• Manufacturer: Schneider Electric
• Part Number: EDB14025
• Series: EDB Series (E-Frame)
• Type: Molded Case Circuit Breaker
• Configuration: 1 Pole
• Amperage Rating: 25A
• Voltage Rating: 277VAC
• Mounting Type: Bolt-On
• Trip Technology: Thermal Magnetic
• Trip Functions: LI (Long-Time and Instantaneous)
• Interrupting Ratings:
  • 18kA @ 277V
  • 25kA @ 240V
  • 25kA @ 120V
• Application Ratings: HID Rated / HACR Rated
• Electrical Connection: Aluminum lugs
• Temperature Rating: 40°C
• Product Destination: Square D NF Panelboard

Applications

• Commercial lighting circuits (HID lighting systems)
• HVAC and motor load protection
• Panelboard branch circuit protection
• Office and institutional electrical distribution
• General commercial building power systems
• Equipment requiring HACR-rated protection

Construction Features

• Bolt-on mounting for secure panelboard installation
• Thermal-magnetic protection for overload and fault conditions
• Trip indicator for quick fault identification
• HID and HACR rated for commercial load compatibility
• Aluminum lug terminals for reliable connections
• Compact E-Frame design for panel efficiency

Certifications & Approvals

• UL Listed (UL 489)
• CSA Certified
• HACR Rated
• HID Rated
• Designed for Square D NF panelboards
• Authentic Schneider Electric / Square D product
