Square D

Square D EDB24015SA E-Frame Molded Case Circuit Breaker – 2 Pole – 15A – 480Y/277VAC – Bolt-On – Thermal Magnetic – Shunt Trip

In stock
SKU: EDB24015SA GTIN/UPC: 785901541844
$774.90
CONDITION
Need Reconditioned? Get Price by Calling
Call Us
Secure transaction
FREE & fast shipping on orders over $149
1 year warranty
30 day returns

Ask an expert

Email 866-972-6370

The Square D EDB24015SA is a molded case circuit breaker engineered for commercial and industrial electrical distribution applications. Designed for use in Schneider Electric NF Panelboards, this 2-pole, 15A breaker delivers reliable thermal-magnetic protection for overload and short-circuit conditions.

Built on the E-Frame platform, the EDB24015SA features a bolt-on mounting system that ensures secure installation and consistent electrical contact within panelboard assemblies. It includes a factory-installed shunt trip for remote switching capability and a Visi-Trip indicator that provides quick visual confirmation of fault conditions, improving troubleshooting efficiency.

Rated for multiple voltage levels, including 480Y/277VAC, this breaker supports a wide range of applications while maintaining high interrupting capacity. Its compact design and accessory compatibility make it suitable for modern electrical distribution systems requiring flexibility and safety.

Specifications

  • Brand: Square D
  • Manufacturer: Schneider Electric
  • Part Number: EDB24015SA
  • Series: EDB Series
  • Type: Molded Case Circuit Breaker (E-Frame)
  • Configuration: 2 Pole
  • Phase: 1 Phase
  • Current Rating: 15A
  • Voltage Rating: 120VAC, 240VAC, 277VAC, 480Y/277VAC, 120/240VAC
  • Mounting Style: Bolt-On
  • Connection Type: Lug Terminal
  • Protection Type: Thermal Magnetic
  • Trip Function: LI – Long-Time and Instantaneous
  • Trip Adjustability: Fixed
  • Application: NF Panelboard

Interrupting Ratings

  • 25kA @ 120VAC
  • 25kA @ 240VAC
  • 18kA @ 277VAC
  • 18kA @ 480Y/277VAC
  • 25kA @ 120/240VAC

Electrical & Mechanical Features

  • Factory-installed shunt trip for remote operation
  • Visi-Trip indicator for quick fault identification
  • Bolt-on mounting for NF Panelboard compatibility
  • Aluminum lug compatibility (Cu/Al wiring support)
  • Thermal-magnetic protection system
  • Fixed trip settings (non-adjustable)
  • Rated for 40°C operation

Wire Range

  • Copper: AWG 14–6
  • Aluminum: AWG 12–6
  • Maximum wire size: AWG 6

Accessories

  • Alarm switch option
  • Auxiliary switch option
  • Padlock attachment capability
  • Factory-installed shunt trip
  • Aluminum lugs included

Standards & Approvals

  • UL 489 Listed
  • CSA C22.2 No. 5
  • IEC 60947-2 Compliant
  • NEMA AB 1
  • CSA, cULus, NOM Approved
  • HACR Rated
  • HID Rated
  • Authentic Square D / Schneider Electric product
  • Designed for NF Panelboard systems
