Square D EDB24050SA E-Frame Molded Case Circuit Breaker – 2 Pole – 50A – 480V – Bolt-On – Thermal Magnetic – LI Function

In stock
SKU: EDB24050SA GTIN/UPC: 785901545828
$774.90
CONDITION
Need Reconditioned? Get Price by Calling
Call Us
Secure transaction
FREE & fast shipping on orders over $149
1 year warranty
30 day returns

Ask an expert

Email 866-972-6370

The Square D EDB24050SA is a molded case circuit breaker designed for industrial and commercial electrical distribution systems. Manufactured by Schneider Electric, this 2-pole, 50A E-Frame breaker is part of the EDB Series and is intended for use in bolt-on NF panelboard applications.

This breaker provides dependable thermal-magnetic protection with LI (Long-Time and Instantaneous) trip functionality, ensuring reliable response to overload and short-circuit conditions. Its bolt-on connection design allows secure installation into compatible panelboards, while maintaining strong electrical integrity in demanding environments.

With a compact molded case construction, the EDB24050SA offers high interrupting performance in a lightweight form factor. It is suitable for a wide range of industrial distribution and control applications where consistent protection and panelboard compatibility are required.

Specifications

  • Brand: Square D
  • Manufacturer: Schneider Electric
  • Part Number: EDB24050SA
  • Series: EDB Series
  • Sub-Category: Molded Case
  • Type: EDB
  • Configuration: 2 Pole
  • Phase: 1 Phase
  • Current Rating: 50A
  • Voltage Rating: 480V AC
  • Connection Type: Bolt-On
  • Protection Type: Thermal Magnetic
  • Trip Function: LI – Long-Time and Instantaneous
  • Application: NF Panelboard

Interrupting Rating

  • 18kA @ 480V

Electrical & Mechanical Features

  • Bolt-on mounting for NF panelboard compatibility
  • Thermal-magnetic trip unit for overload and short-circuit protection
  • LI (Long-Time and Instantaneous) protection function
  • Compact molded case E-Frame design
  • High interrupting capacity for industrial applications
  • Lightweight construction (1.44 lbs)

Physical Data

  • Weight: 1.44 lbs

General Application Areas

  • Industrial power distribution systems
  • Commercial electrical panelboards
  • OEM equipment and machinery
  • NF panelboard installations
  • General branch circuit protection

Standards & Compliance

  • Designed for NF panelboard systems
  • Manufactured by Schneider Electric
  • Authentic Square D product
  • Industrial-grade molded case breaker design
