Square D EDB24100SA E-Frame Molded Case Circuit Breaker – 2 Pole – 100A – Bolt-On – Thermal Magnetic – 120VAC Shunt Trip

The Square D EDB24100SA is a molded case circuit breaker engineered for commercial and industrial electrical distribution systems requiring remote tripping capability. Manufactured by Schneider Electric, this 2-pole, 100A breaker features a factory-installed 120VAC shunt trip that enables remote circuit disconnection for enhanced control and safety applications.

Designed for installation in NF panelboards, the EDB24100SA utilizes a bolt-on mounting configuration and requires three panelboard pole spaces due to the integrated shunt trip accessory. The breaker provides dependable thermal-magnetic protection with fixed long-time and instantaneous trip characteristics, helping protect electrical systems from overload and short-circuit conditions.

A built-in Visi-Trip indicator allows rapid identification of tripped circuits, reducing troubleshooting time and simplifying maintenance. With interrupting ratings up to 25kA at 240VAC, this breaker is well suited for demanding commercial and industrial power distribution applications.

Specifications

• Brand: Square D
• Manufacturer: Schneider Electric
• Part Number: EDB24100SA
• Series: EDB Series
• Type: Molded Case Circuit Breaker (E-Frame)
• Configuration: 2 Pole
• Phase: 1 Phase
• Current Rating: 100A
• Voltage Rating: 120VAC, 240VAC, 277VAC, 480Y/277VAC, 120/240VAC
• Mounting Style: Bolt-On
• Connection Type: Lug Terminal
• Protection Type: Thermal Magnetic
• Trip Function: LI – Long-Time and Instantaneous
• Trip Adjustability: Fixed Thermal, Fixed Magnetic
• Application: NF Panelboard

Interrupting Ratings

• 25kA @ 120VAC
• 25kA @ 240VAC
• 18kA @ 277VAC
• 18kA @ 480Y/277VAC
• 25kA @ 120/240VAC

Electrical & Mechanical Features

• Factory-installed 120VAC shunt trip for remote circuit disconnection
• Requires three NF panelboard pole spaces due to integrated accessory
• Thermal-magnetic protection for overload and short-circuit conditions
• Fixed thermal and magnetic trip characteristics
• Visi-Trip visual trip indicator for quick fault identification
• Bolt-on mounting for secure installation
• HACR rated construction
• Rated for 40°C operating environments

Wire Range

• Copper: AWG 14–2/0
• Aluminum: AWG 12–2/0
• Maximum wire size: 2/0 AWG
• Minimum wire size: AWG 14 Copper / AWG 12 Aluminum

Accessories

• Factory-installed 120VAC shunt trip
• Load-side lugs included
• Aluminum lugs included
• Padlock attachment option
• Lug kit options available

Standards & Approvals

• UL 489 Listed
• CSA C22.2 No. 5
• IEC 60947-2 Compliant
• NEMA AB 1
• CSA Approved
• cULus Listed
• NOM Approved
• UL Listed
• Authentic Square D / Schneider Electric product
• Designed for NF Panelboard systems
