Square D EGB34060SA E-Frame Molded Case Circuit Breaker – 3 Pole – 60A – Bolt-On – Thermal Magnetic – 120VAC Shunt Trip

The Square D EGB34060SA is a molded case circuit breaker designed for commercial and industrial power distribution systems requiring reliable protection with remote switching capability. Manufactured by Schneider Electric, this 3-pole, 60A E-Frame breaker delivers dependable thermal-magnetic protection for overload and short-circuit conditions in three-phase electrical installations.

This model includes a factory-installed 120VAC shunt trip, allowing remote or automated circuit interruption for emergency shutdown systems, control integration, and facility safety applications. It mounts securely into NF panelboards using a bolt-on connection designed for stable, long-term operation in demanding environments.

With a high interrupting rating of 65kA at 240VAC and 35kA at 480Y/277VAC, the EGB34060SA provides strong fault protection performance suitable for commercial distribution systems. A Visi-Trip indicator enhances maintenance efficiency by enabling quick visual identification of tripped circuits.

Specifications

• Brand: Square D
• Manufacturer: Schneider Electric
• Part Number: EGB34060SA
• Series: EGB Series
• Type: Molded Case Circuit Breaker (E-Frame)
• Configuration: 3 Pole
• Phase: 3 Phase
• Current Rating: 60A
• Voltage Rating: 120VAC, 240VAC, 480Y/277VAC
• Mounting Style: Bolt-On
• Connection Type: Lug Terminal
• Protection Type: Thermal Magnetic
• Trip Function: LI – Long-Time and Instantaneous
• Trip Adjustability: Fixed Thermal, Fixed Magnetic
• Application: NF Panelboard / Commercial Power Distribution

Interrupting Ratings

• 65kA @ 120VAC
• 65kA @ 240VAC
• 35kA @ 480Y/277VAC

Electrical & Mechanical Features

• Factory-installed 120VAC shunt trip for remote and automated control
• Thermal-magnetic overload and short-circuit protection
• Bolt-on NF panelboard mounting system
• Visi-Trip visual fault indicator
• HACR rated construction for HVAC applications
• Designed for three-phase commercial distribution systems
• Fixed trip characteristics for consistent protection performance
• Suitable for emergency shutdown and control integration systems

Wire Range

• Copper: AWG 14–2/0
• Aluminum: AWG 12–2/0
• Maximum wire size: 2/0 AWG
• Minimum wire size: AWG 14 Copper / AWG 12 Aluminum

Accessories

• Factory-installed 120VAC shunt trip
• Auxiliary switch option
• Alarm switch option
• Padlock attachment option

Standards & Approvals

• UL 489 Listed
• CSA C22.2 No. 5
• NFPA 70 Compliant
• NEMA AB 1 Compliant
• CSA Approved
• cULus Listed
• HACR Rated
• NOM Approved
• Authentic Square D / Schneider Electric product
• Designed for NF Panelboard systems
