Square D HDA260252 PowerPact Circuit Breaker – 2 Pole – 25A – 600V – Thermal Magnetic – I-Line Plug-In – 18kA @ 480V

The Schneider Electric HDA260252 PowerPact Circuit Breaker is a durable and reliable molded case circuit breaker designed for commercial and industrial power distribution applications. Part of the Square D PowerPact family, this 2-pole breaker provides dependable overload and short-circuit protection through a non-interchangeable thermal-magnetic trip unit featuring Long-Time and Instantaneous (LI) protection functions.

Rated at 25A and 600V AC, the HDA260252 is built on the H-Frame platform and utilizes an I-Line style plug-in connection for fast installation and secure integration into compatible Schneider Electric I-Line panelboards and distribution equipment. Its thermal element protects against sustained overload conditions, while the instantaneous magnetic trip mechanism responds quickly to fault currents, helping safeguard electrical systems and connected equipment.

With a standard interrupting capacity of 18kA at 480V AC, this breaker is suitable for a wide range of branch circuit and feeder protection applications. The unit is UL listed and approved for reverse-fed installations, making it a versatile solution for modern electrical distribution systems.

Specifications

• Brand: Square D by Schneider Electric
• Manufacturer: Schneider Electric
• Part Number: HDA260252
• Product Family: PowerPact
• Frame Type: H Frame
• Device Type: Molded Case Circuit Breaker
• Number of Poles: 2 Pole
• Phase: 1 Phase
• Current Rating: 25A
• Voltage Rating: 600V AC
• Connection Type: I-Line Style Plug-In
• Protection Type: Thermal Magnetic
• Trip Functions: LI (Long-Time and Instantaneous)
• Trip Unit: Non-Interchangeable
• Category: Molded Case Breakers / 2-Pole

Electrical Performance

• Rated Current: 25A
• Maximum Voltage: 600V AC
• Interrupting Capacity: 18kA @ 480V AC
• Protection Functions: Long-Time and Instantaneous Trip
• Overload Protection: Thermal Trip Element
• Short-Circuit Protection: Magnetic Instantaneous Trip
• A & C Phase Connection: Yes
• Suitable for Reverse Feed Applications: Yes

Mechanical & Construction Features

• H-Frame molded case construction
• I-Line plug-in mounting configuration
• Compact industrial design
• Non-interchangeable trip unit
• Durable molded case housing
• Secure plug-in installation
• Designed for commercial and industrial power systems
• Long service life and dependable operation

Electrical Connections

• Line Connection: I-Line Style Plug-In
• Load Connection: Lug Terminals
• Compatible with Schneider Electric I-Line Distribution Equipment

Dimensions & Weight

• Dimensions (H × W × D): 3.39" × 4.09" × 6.42"
• Weight: 4.85 lb

Applications

• Commercial power distribution systems
• Industrial electrical installations
• Branch circuit protection
• Feeder circuit protection
• I-Line panelboards and switchboards
• OEM equipment and control panels
• Manufacturing facilities
• Electrical distribution equipment

Standards & Certifications

• UL Listed
• CSA Approved
• Suitable for reverse-fed applications
• Manufactured to applicable molded case circuit breaker standards
