Square D HDA260802 PowerPact Circuit Breaker – 2 Pole – 80A – 600V – Thermal Magnetic – I-Line Plug-In – 18kA @ 480V

The Square D HDA260802 PowerPact Circuit Breaker is a molded case circuit breaker designed for reliable protection of electrical distribution systems in commercial and industrial applications. Manufactured by Schneider Electric under the PowerPact H-Frame series, this 2-pole breaker provides dependable thermal-magnetic protection for overload and short-circuit conditions while offering convenient I-Line plug-in installation.

Rated at 80A and 600V AC, the HDA260802 features a non-interchangeable thermal-magnetic trip unit with Long-Time and Instantaneous (LI) protection functions. The thermal element protects against sustained overloads, while the magnetic trip mechanism responds instantly to high fault currents, helping to protect downstream equipment and maintain system safety.

Designed for Square D I-Line panelboards and switchboards, the breaker uses an I-Line style plug-in connection for fast installation and replacement. Its A & C phase configuration and H-Frame construction make it suitable for a wide range of commercial and industrial power distribution applications requiring compact and reliable circuit protection.

With a standard interrupting capacity of 18kA at 480V AC and reverse-feed capability, the HDA260802 is well-suited for branch and feeder circuit protection in demanding electrical environments.

Specifications

• Brand: Square D by Schneider Electric
• Manufacturer: Schneider Electric
• Part Number: HDA260802
• Product Family: PowerPact
• Series: HDA Series
• Frame Type: H-Frame
• Device Type: Molded Case Circuit Breaker
• Number of Poles: 2 Pole
• Phase: 1 Phase
• Current Rating: 80A
• Voltage Rating: 600V AC
• Connection Type: I-Line Style Plug-In
• Mounting Mode: I-Line Bracket
• Protection Type: Thermal Magnetic
• Trip Unit Technology: Thermal-Magnetic
• Trip Functions: LI (Long-Time and Instantaneous)
• Control Type: Toggle
• Breaking Capacity Code: D
• Phase Connection: A & C Phase

Electrical Performance

• Rated Current: 80A
• Maximum Voltage: 600V AC
• Interrupting Capacity: 18kA @ 480V AC
• Continuous Current Rating: 80%
• Magnetic Hold Current: 800A
• Trip Unit: Non-Interchangeable
• Overload Protection: Long-Time Thermal Trip
• Short-Circuit Protection: Instantaneous Magnetic Trip
• Suitable for Reverse Feed Applications: Yes

Mechanical & Construction Features

• H-Frame molded case construction
• Compact industrial-grade design
• I-Line plug-in mounting system
• Toggle handle operation
• Non-interchangeable thermal-magnetic trip unit
• Rugged molded insulating case
• Designed for commercial and industrial power distribution systems
• Reliable long-term performance and protection

Electrical Connections

• Line Connection: I-Line Plug-In
• Load Connection: Lug Terminals
• Conductor Compatibility: Copper or Aluminum
• Wire Size Range: AWG 14 to AWG 3/0

Dimensions & Weight

• Dimensions (H × W × D): 3.39" × 4.09" × 6.42"
• Weight: 4.85 lb

Applications

• Commercial electrical distribution systems
• Industrial power distribution equipment
• Branch circuit protection
• Feeder circuit protection
• Square D I-Line panelboards
• Square D I-Line switchboards
• Manufacturing facilities
• OEM control panels and equipment
• Electrical infrastructure maintenance and upgrades
