Square D HDL26030 30 Amp 2-Pole Molded Case Circuit Breaker – Feed-Thru – 600V AC

The Schneider Electric Square D PowerPact HDL26030 is a 30 Amp, 2-pole molded case circuit breaker designed for reliable protection of electrical systems against overloads and short circuits. Built on the H-Frame PowerPact platform, it is commonly used in industrial and commercial distribution applications.

This breaker uses a feed-thru connection design and thermal-magnetic protection technology, offering dependable and consistent performance in standard power distribution systems.

Electrical Ratings

• Current Rating: 30 Amps
• Voltage Rating: 600 Volts AC
• Phase: Single Phase (1PH)
• Interrupting Capacity: 18 kA @ 480V AC
• Breaking Capacity: 14 kA @ 600V AC
• Continuous Current Rating: 80%
• Frame Type: H-Frame

Breaker & Protection Features

• Breaker Type: Molded Case Circuit Breaker (MCCB)
• Number of Poles: 2-Pole
• Trip Unit Technology: Thermal-Magnetic
• Trip Functions: Long-Time and Instantaneous protection
• Protection Type: Overload and short-circuit protection
• Manual Operation: Integrated push-to-trip test button
• Contact Design: Dual-break rotating contacts for reduced fault current peaks

Mounting & Connection

• Connection Type: Feed-Thru
• Electrical Connection: Line and load lugs
• Installation Type: Unit mount / H-Frame compatible panel systems
• Configuration: Available in both 2-pole and 3-pole H-Frame designs

Wiring & Termination

• Terminal Type: Lug connections on both line and load sides
• Conductor Compatibility: Industrial copper/aluminum conductors (application dependent)
• Wiring Style: Feed-through configuration for simplified wiring layout

Physical Specifications

• Compact H-Frame molded case design
• Standard industrial enclosure footprint for H-Frame series
• Weight: Not specified in provided data

Certifications & Standards

• UL Listed
• CSA Approved
• NOM Certified
• IEC Compliant
• CE Marked
• Meets international industrial circuit protection standards

Additional Features

• Dual-break rotating contact system reduces peak fault current
• Built-in push-to-trip manual test button
• High reliability thermal-magnetic protection
• Feed-thru design for flexible industrial wiring
• Suitable for industrial and commercial distribution systems
