Square D HGA260301 30 Amp 2-Pole Molded Case Circuit Breaker – I-Line Plug-In – 600V AC

The Schneider Electric Square D PowerPact HGA260301 is a 30 Amp, 2-pole molded case circuit breaker designed for industrial I-Line panelboard systems. It provides dependable overload and short-circuit protection for distribution circuits in commercial and industrial applications.

Built on the H-Frame PowerPact platform, this breaker uses thermal-magnetic protection with LI (Long-Time and Instantaneous) trip functions and is suitable for reverse-fed installations.

Electrical Ratings

• Current Rating: 30 Amps
• Voltage Rating: 600V AC
• Phase: 1-Phase
• Interrupting Capacity: 35 kA @ 480V AC
• Frame Type: H-Frame
• Application Category: Molded Case Circuit Breaker (MCCB)

Breaker & Protection Features

• Breaker Type: MCCB (Molded Case Circuit Breaker)
• Number of Poles: 2-Pole
• Trip Unit Technology: Thermal-Magnetic
• Trip Functions: LI (Long-Time & Instantaneous)
• Protection Type: Overload and short-circuit protection
• Trip Unit: Non-interchangeable
• Control Type: Toggle mechanism

Mounting & Connection

• Connection Type: I-Line Style Plug-In
• Electrical Connection: Line – I-Line connection / Load – lugs
• Mounting Style: I-Line panelboard mounting system
• Compatibility: Square D PowerPact H-Frame panels
• Reverse Feed Compatible: Yes

Wiring & Termination

• Phase Connection: A & B phase configuration
• Terminal Type: Load-side lug connections
• Wire Size Range: Industrial copper/aluminum conductors (application dependent)
• Installation Type: Plug-in breaker system

Physical Specifications

• Height: 3.39 in
• Width: 4.09 in
• Depth: 6.42 in
• Weight: 4.85 lb

Certifications & Standards

• UL Listed
• CSA Approved
• Designed for industrial-grade electrical distribution
• Complies with international MCCB safety standards

Additional Features

• High interrupting capacity design (35kA @ 480V)
• Thermal-magnetic LI protection system
• I-Line plug-in installation for fast mounting
• Suitable for reverse-fed applications
• Reliable protection for industrial and commercial panels

Manufacturer Information

• Manufacturer: Schneider Electric
• Brand: Square D
• Series: PowerPact H-Frame
• Model: HGA260301
