Square D HGA260302 30 Amp 2-Pole Molded Case Circuit Breaker – I-Line Plug-In – 600V AC

The Schneider Electric Square D PowerPact HGA260302 is a 30 Amp, 2-pole molded case circuit breaker designed for industrial and commercial power distribution systems. Built on the H-Frame PowerPact platform, it delivers reliable thermal-magnetic protection against overloads and short circuits.

It features an I-Line plug-in connection system for fast installation in compatible panelboards and supports reverse-fed applications for flexible system design.

Electrical Ratings

• Current Rating: 30 Amps
• Voltage Rating: 600 Volts AC
• Phase: 1-Phase
• Interrupting Capacity: 35 kA @ 480V AC
• Frame Type: H-Frame
• Application Category: Molded Case Circuit Breaker (MCCB)
• Breaking Capacity Code: G

Breaker & Protection Features

• Breaker Type: MCCB (Molded Case Circuit Breaker)
• Number of Poles: 2-Pole
• Trip Unit Technology: Thermal-Magnetic
• Trip Functions: LI (Long-Time and Instantaneous protection)
• Protection Type: Overload and short-circuit protection
• Magnetic Hold Current: 350 A
• Control Type: Toggle mechanism
• Trip Unit: Non-interchangeable

Mounting & Connection

• Connection Type: I-Line Style Plug-In
• Mounting Mode: I-Line bracket system
• Electrical Connection: Line – I-Line connection / Load – lugs
• Installation Type: Plug-in breaker for PowerPact H-Frame panels
• Compatibility: Square D PowerPact systems
• Reverse Feed Compatible: Yes

Wiring & Termination

• Wire Size Range: AWG 14 to 3/0 (Aluminum/Copper conductors)
• Terminal Type: Lug terminals (load side)
• Phase Configuration: A & C phase connection
• Wiring Style: Plug-in I-Line system

Physical Specifications

• Height: 9.73 in
• Width: 2.94 in
• Depth: 4.8 in
• Weight: 4.85 lbs

Certifications & Standards

• UL Listed
• CSA Approved
• Designed for industrial electrical distribution systems
• Complies with international MCCB standards

Additional Features

• High interrupting capacity (35kA @ 480V)
• Thermal-magnetic LI protection system
• I-Line plug-in design for fast installation
• Suitable for reverse-fed applications
• Compact H-Frame construction for panel efficiency
