Square D HGA260502 50 Amp 2-Pole Molded Case Circuit Breaker – I-Line Plug-In – 600V AC

The Schneider Electric Square D PowerPact HGA260502 is a 50 Amp, 2-pole molded case circuit breaker designed for industrial I-Line panelboard systems. It provides dependable overload and short-circuit protection using thermal-magnetic technology.

Built on the H-Frame PowerPact platform, it supports reverse-fed applications and is designed for fast plug-in installation in compatible Square D distribution equipment.

Electrical Ratings

• Current Rating: 50 Amps
• Voltage Rating: 600V AC
• Phase: 1-Phase
• Interrupting Capacity: 35 kA @ 480V AC
• Frame Type: H-Frame
• Application Category: Molded Case Circuit Breaker (MCCB)
• Breaking Capacity Code: G

Breaker & Protection Features

• Breaker Type: MCCB (Molded Case Circuit Breaker)
• Number of Poles: 2-Pole
• Trip Unit Technology: Thermal-Magnetic
• Trip Functions: LI (Long-Time and Instantaneous)
• Protection Type: Overload and short-circuit protection
• Magnetic Hold Current: 400 A
• Control Type: Toggle mechanism
• Trip Unit: Non-interchangeable

Mounting & Connection

• Connection Type: I-Line Style Plug-In
• Mounting Mode: I-Line bracket system
• Electrical Connection: Line – I-Line connection / Load – lugs
• Phase Configuration: A & C phase connection
• Installation Type: Plug-in breaker system
• Compatibility: Square D PowerPact H-Frame panels
• Reverse Feed Compatible: Yes

Wiring & Termination

• Wire Size Range: AWG 14 to 3/0 (Aluminum/Copper conductors)
• Terminal Type: Lug terminals (load side)
• Wiring Style: I-Line plug-in configuration

Physical Specifications

• Height: 9.73 in
• Width: 2.94 in
• Depth: 4.8 in
• Weight: 4.85 lbs

Certifications & Standards

• UL Listed
• CSA Approved
• Designed for industrial electrical distribution systems
• Complies with international MCCB safety standards

Additional Features

• High interrupting capacity (35kA @ 480V)
• Thermal-magnetic LI protection system
• I-Line plug-in design for fast installation
• Suitable for reverse-fed applications
• Compact H-Frame construction for panel efficiency

Manufacturer InformatioN

• Manufacturer: Schneider Electric
• Brand: Square D
• Series: PowerPact H-Frame
• Model: HGA260502
