Square D HGL36035 35 Amp 3-Pole Molded Case Circuit Breaker – Feed-Thru – 600V AC

The Schneider Electric Square D PowerPact HGL36035 is a 35 Amp, 3-pole molded case circuit breaker designed for industrial and commercial electrical distribution systems. It belongs to the H-Frame PowerPact series and provides reliable thermal-magnetic protection for overloads and short-circuit conditions.

This model uses a feed-thru (line-and-load lug) configuration and is designed for use in panelboards requiring high interrupting capacity and compact H-frame construction.

Electrical Ratings

• Current Rating: 35 Amps
• Voltage Rating: 600 Volts AC
• Phase: 3-Phase (ABC configuration)
• Interrupting Capacity: 18 kA @ 600V AC (up to higher ratings at lower voltages)
• Frame Type: H-Frame
• Application Category: Molded Case Circuit Breaker (MCCB)

Breaker & Protection Features

• Breaker Type: MCCB (Molded Case Circuit Breaker)
• Number of Poles: 3-Pole
• Trip Unit Technology: Thermal-Magnetic
• Trip Functions: LI (Long-Time and Instantaneous protection)
• Protection Type: Overload and short-circuit protection
• Trip Unit: Non-interchangeable
• Control Type: Toggle mechanism

Mounting & Connection

• Connection Type: Feed-Thru
• Electrical Connection: Line and load lug terminals
• Installation Type: H-Frame PowerPact panel system
• Compatibility: Square D PowerPact distribution panels
• Reverse Feed Compatible: Yes

Wiring & Termination

• Wire Size Range: AWG 14 to 3/0 (Aluminum/Copper conductors)
• Terminal Type: Lug connections (line and load sides)
• Wiring Style: Feed-through configuration for flexible installation

Physical Specifications

• Height: ~3.39 in
• Width: ~4.09 in
• Depth: ~6.42 in
• Weight: ~4.8–5 lb (varies slightly by configuration)

Certifications & Standards

• UL Listed
• CSA Approved
• IEC compliant (varies by configuration)
• NOM certified
• Designed for industrial electrical safety standards

Additional Features

• Dual-break rotating contact system for reduced fault current stress
• Built-in push-to-trip manual test function
• High interrupting capacity for industrial fault conditions
• Compact H-frame design for efficient panel space usage
• Suitable for reverse-fed applications
• Commonly used in HVAC, industrial feeders, and solar/distribution systems

Manufacturer Information

• Manufacturer: Schneider Electric
• Brand: Square D
• Series: PowerPact H-Frame
• Model: HGL36035
