Square D HJA36100U33X 100 Amp 3-Pole Molded Case Circuit Breaker – I-Line Plug-In – 600V AC

The Schneider Electric Square D PowerPact HJA36100U33X is a 100 Amp, 3-pole molded case circuit breaker designed for high-performance industrial power distribution systems. Built on the HJA PowerPact frame, it provides advanced solid-state protection with LSI (Long-Time, Short-Time, Instantaneous) trip functionality.

It is engineered for I-Line plug-in installation and supports reverse-fed applications, making it suitable for flexible and high-fault-capacity electrical systems.

Electrical Ratings

• Current Rating: 100 Amps
• Voltage Rating: 600 Volts AC
• Phase: 3-Phase (ABC connection)
• Interrupting Capacity: 65 kA @ 480V AC
• Frame Type: HJA Frame (High-interrupting H-frame variant)
• Application Category: Molded Case Circuit Breaker (MCCB)
• Current Limiting: Yes

Breaker & Protection Features

• Breaker Type: MCCB (Molded Case Circuit Breaker)
• Number of Poles: 3-Pole
• Trip Unit Technology: Solid State electronic (Micrologic 3.2S type)
• Trip Functions: LSI (Long-Time, Short-Time, Instantaneous)
• Protection Type: Advanced electronic protection
• Trip Unit: Non-interchangeable
• Control Type: Toggle mechanism

Mounting & Connection

• Connection Type: I-Line Style Plug-In
• Installation Type: Plug-in breaker for panelboard systems
• Electrical Connection: Line – I-Line connection / Load – lugs
• Compatibility: Square D PowerPact systems
• Reverse Feed Compatible: Yes
• Application Flexibility: Can be used in 2-pole configurations where required

Wiring & Termination

• Terminal Type: Lug terminals (line and load side)
• Wire Size Range: Industrial copper/aluminum conductors (application dependent)
• Wiring Style: I-Line plug-in configuration

Physical Specifications

• Weight: 4.85 lb
• Compact industrial molded case design

Certifications & Standards

• UL Listed
• CSA Approved
• Designed for industrial-grade electrical distribution
• Complies with international MCCB standards
• Suitable for high fault current applications

Additional Features

• High interrupting capacity (65kA @ 480V)
• Current limiting design for enhanced protection
• Solid-state LSI trip coordination
• I-Line plug-in for fast installation
• Suitable for reverse-fed applications
• Compact H-frame industrial construction

Manufacturer Information

• Manufacturer: Schneider Electric
• Brand: Square D
• Series: PowerPact HJA Frame
• Model: HJA36100U33X
