Square D HLL36015 15 Amp 3-Pole Molded Case Circuit Breaker – Feed-Thru – 600V AC

The Schneider Electric Square D PowerPact HLL36015 is a 15 Amp, 3-pole molded case circuit breaker designed for high-performance industrial and commercial electrical distribution systems. Built on the H-Frame PowerPact platform, it delivers reliable thermal-magnetic protection for overload and short-circuit conditions.

It features a feed-thru (lug-to-lug) connection system and is suitable for reverse-fed applications, making it flexible for a wide range of panelboard installations.

Electrical Ratings

• Current Rating: 15 Amps
• Voltage Rating: 600 Volts AC
• Phase: 3-Phase
• Interrupting Capacity: 100 kA @ 480V AC
• Frame Type: H-Frame (HLL variant)
• Application Category: Molded Case Circuit Breaker (MCCB)
• Current Limiting: Yes
• Breaking Capacity Code: L

Breaker & Protection Features

• Breaker Type: MCCB (Molded Case Circuit Breaker)
• Number of Poles: 3-Pole
• Trip Unit Technology: Thermal-Magnetic
• Trip Functions: LI (Long-Time and Instantaneous)
• Protection Type: Overload and short-circuit protection
• Magnetic Hold Current: 350 A
• Control Type: Toggle mechanism
• Trip Unit: Non-interchangeable

Mounting & Connection

• Connection Type: Feed-Thru
• Electrical Connection: Lug line / Lug load
• Installation Type: Unit mount lug system
• Compatibility: Square D PowerPact H-Frame panels
• Reverse Feed Compatible: Yes

Wiring & Termination

• Wire Size Range: AWG 14 to 3/0 (Aluminum/Copper conductors)
• Terminal Type: Line and load lug terminals
• Wiring Style: Feed-through configuration

Physical Specifications

• Height: 6.4 in
• Width: 4.12 in
• Depth: 4.36 in
• Weight: 4.85 lbs

Certifications & Standards

• UL Listed
• CSA Approved
• Designed for industrial-grade electrical distribution systems
• High interrupting capacity MCCB standard
• Suitable for reverse-fed applications

Additional Features

• High interrupting capacity (100kA @ 480V)
• Current limiting H-frame design
• Thermal-magnetic LI protection system
• Feed-thru lug-to-lug construction
• Compact industrial breaker design
• Reliable performance in high fault-current systems

Manufacturer Information

• Manufacturer: Schneider Electric
• Brand: Square D
• Series: PowerPact HLL Frame
• Model: HLL36015
