Square D HOMT2020250 20A/20A/50A Quad Tandem Circuit Breaker – Plug-In – 120/240V

The Square D Homeline HOMT2020250 is a quad tandem circuit breaker featuring two 20A 1-Pole breakers and one 50A 2-Pole breaker in a compact 2-space configuration. Designed for Homeline loadcenters, it provides reliable 120/240V AC protection for residential and light commercial applications. With a 10kA interrupt rating and plug-in mounting, it ensures dependable overload and short-circuit protection while maximizing panel capacity.

Electrical Ratings:

• Amperage: (2) 20 Amps 1-Pole, (1) 50 Amps 2-Pole
• Poles: 1P + 1P + 2P configuration
• Voltage: 120/240 Volts AC
• Interrupt Rating: 10 kAIC

Key Specifications:

• Breaker Type: Quad Tandem (CTL)
• Mounting Mode: Plug-in
• Connections Terminals: Box lugs
• Wire Size: 50A section: (1) #14–6 AWG Cu / #12–6 AWG Al; 20A sections: (1) #14–8 AWG Cu/Al or (2) #14–10 AWG Cu/Al
• Tightening Torque: 35.4 lb-in

Dimensions & Weight:

• • Height: 3.13 in
  • Width: 2.0 in
  • Depth: 2.98 in
  • Weight: 0.85 lbs

Certifications:

• UL Listed
• HACR Rated

Product Data:

• Manufacturer: Schneider Electric
• Brand: Square D
• Product Range: Homeline (for Square D Homeline loadcenters and equipment)
• Model Number: HOMT2020250
• UPC: 785901377054
