Square D JDA36175SA 175A 3-Pole Thermal Magnetic Molded Case Circuit Breaker – I-Line Plug-In – 600V – 120VAC Shunt Trip

In stock
SKU: JDA36175SA GTIN/UPC: 785901695622
$2,480.41
CONDITION
Need Reconditioned? Get Price by Calling
Call Us
Secure transaction
FREE & fast shipping on orders over $149
1 year warranty
30 day returns

Ask an expert

Email 866-972-6370

The Square D JDA36175SA PowerPacT J-Frame circuit breaker is a high-performance molded case circuit breaker designed to protect commercial and industrial electrical systems against overloads and short circuits. Rated at 175 Amps with a 3-pole configuration, this breaker features a thermal-magnetic trip unit and an integrated factory-installed 120VAC shunt trip for remote tripping capability. The I-Line plug-in design allows for quick installation and removal in I-Line distribution equipment, while dual-break rotating contacts help minimize peak fault currents during short-circuit events. Engineered for reliability and safety, the JDA36175SA complies with major North American and international standards.

Voltage and Rating

  • Current Rating: 175 Amps
  • Voltage Rating: 600 Volts AC
  • Interrupting Capacity: 18 kAIC at 480VAC
  • Breaking Capacity: 14 kA at 600VAC
  • Phase: Three Phase
  • Continuous Current Rating: 80%

Key Specifications

  • Breaker Type: Molded Case Circuit Breaker
  • Number of Poles: 3-Pole
  • Series: PowerPacT J-Frame
  • Model: JDA36175SA
  • Trip Unit Type: Thermal Magnetic
  • Mounting Type: I-Line Style Plug-In
  • Connection Type: I-Line Line Side / Mechanical Lug Load Side
  • Frame Type: J-Frame
  • Functions: Long-Time and Instantaneous (LI)
  • Protection Type: Overload and Short Circuit Protection
  • Phase Connection: ABC Phase Connection
  • Factory-Installed Accessory: 120VAC Shunt Trip
  • Application: Commercial and Industrial Power Distribution

Technical Specifications

  • Trip Technology: Thermal-Magnetic
  • Interrupt Rating: 18 kAIC @ 480VAC
  • Breaking Capacity: 14 kA @ 600VAC
  • Contact Design: Dual-Break Rotating Contacts
  • Electrical Connection:
    • Line Side: I-Line Plug-In
    • Load Side: Mechanical Lugs
  • Mounting Configuration: I-Line Construction
  • Shunt Trip Voltage: 120VAC
  • Push-to-Trip Button: Integral Manual Trip Feature
  • Suitable for Power Distribution Applications
  • CE Marked

Certifications and Standards

  • UL Listed
  • CSA Certified
  • NOM Certified
  • IEC Compliant
  • CE Marked

Product Data

  • Manufacturer: Schneider Electric / Square D
  • Family: PowerPacT
  • Part Number: JDA36175SA
  • Frame Type: J-Frame
  • Category: Molded Case Circuit Breaker

Features

  • Thermal-magnetic protection against overload and short-circuit conditions
  • Factory-installed 120VAC shunt trip for remote tripping applications
  • I-Line plug-in mounting for fast installation and maintenance
  • Dual-break rotating contacts reduce peak short-circuit currents
  • Integral push-to-trip button for testing and inspection
  • Designed for industrial and commercial electrical distribution systems
  • Durable molded case construction for long-term reliability
  • Compatible with Square D I-Line distribution equipment
  • Meets UL, CSA, NOM, and IEC standards for safety and performance.
