Square D JDL36200SA PowerPact J Molded Case Circuit Breaker – 3 Pole – 200A – 600VAC – Thermal Magnetic – Feed-Thru – Shunt Trip

The Square D JDL36200SA PowerPact J molded case circuit breaker is designed for reliable power distribution and protection against overloads and short circuits in commercial and industrial electrical systems. This 3-pole, 200A breaker features thermal-magnetic trip technology and a current-limiting design that helps reduce fault current stress on connected equipment. The feed-thru configuration includes line and load lug terminals for straightforward installation.

The JDL36200SA is rated for up to 600VAC and provides an interrupting capacity of 18kA at 480VAC and 14kA at 600VAC. It includes a factory-installed 100/130VAC shunt trip for remote tripping capability, making it suitable for emergency shutdown and control applications. Built on the PowerPact J-Frame platform, this breaker offers dependable protection, UL and CSA approvals, and compliance with major industry standards.

Specifications:

• Manufacturer: Schneider Electric / Square D
• Part Number: JDL36200SA
• Product Line: PowerPact J
• Type: JDL
• Frame Type: J-Frame
• Product Type: Molded Case Circuit Breaker
• Protection Type: Thermal Magnetic
• Trip Functions: Long-Time and Instantaneous (LI)
• Number of Poles: 3
• Phase: 3 Phase
• Current Rating: 200 Amp
• Voltage Rating: 600 VAC Maximum
• Maximum DC Voltage: 250 VDC
• Interrupting Rating:
  • 25kA @ 240VAC
  • 18kA @ 480VAC
  • 14kA @ 600VAC
  • 20kA @ 250VDC
• Continuous Current Rating: 80%
• Connection Type: Feed-Thru
• Terminal Type: Line Lug / Load Lug
• Mounting Type: Unit Mount
• Control Type: Toggle
• Trip Setting Range: 1000A to 2000A
• Shunt Trip: Factory Installed, 100/130VAC
• Wire Size Range: 3/0 AWG to 350 kcmil Copper/Aluminum
• Dimensions (H × W × D): 7.52 × 4.09 × 3.39 in
• Application: Power Distribution
• Operating Temperature: 28°F to 158°F (-2°C to 70°C)
• Standards: UL, CSA, CE, NOM, NEMA, IEC Compliant
• Features:
  • Current-Limiting Design
  • Overload and Short-Circuit Protection
  • Dual-Break Rotating Contacts
  • Integral Push-to-Trip Button
  • Factory-Installed Shunt Trip
  • Suitable for Commercial and Industrial Applications
