Square D JGL36250U33X Molded Case Circuit Breaker – 3 Pole – 250A – 600V – Feed-Thru – Solid State – LSI Protection

In stock
SKU: JGL36250U33X GTIN/UPC: 78590150682
$3,064.51
CONDITION
Need Reconditioned? Get Price by Calling
Call Us
Secure transaction
FREE & fast shipping on orders over $149
1 year warranty
30 day returns

Ask an expert

Email 866-972-6370

The Square D JGL36250U33X PowerPact molded case circuit breaker is designed to provide advanced overload and short-circuit protection for commercial and industrial power distribution systems. Equipped with a MicroLogic 3.2 S electronic trip unit, this breaker delivers Long-Time, Short-Time, and Instantaneous (LSI) protection for enhanced system coordination and equipment protection. Its feed-thru configuration features line and load side lug terminals for convenient installation in switchboards, panelboards, and distribution equipment. Rated at 250A and 600V, the JGL36250U33X offers high interrupting capacity ratings of 35kA at 480VAC, 18kA at 600VAC, and 65kA at 240VAC. The breaker is suitable for reverse-fed applications and can also be used in 2-pole applications, providing installation flexibility for a variety of power distribution requirements.

Voltage and Current Ratings

  • Current Rating: 250 Amps
  • Voltage Rating: 600 Volts AC
  • Phase: 3 Phase
  • Continuous Current Rating: 80%

Interrupting Rating

  • 65kA at 240VAC
  • 35kA at 480VAC
  • 18kA at 600VAC
  • High Interrupting Capacity

Trip Unit and Protection

  • Protection Type:
    • Overload Protection
    • Short-Circuit Protection
  • Trip Unit Technology: Electronic, Standard, MicroLogic 3.2 S
  • Trip Functions:
    • Long-Time (L)
    • Short-Time (S)
    • Instantaneous (I)
  • Non-Interchangeable Trip Unit
  • Solid State Protection

Configuration and Mounting

  • Poles: 3 Pole
  • Frame Type: J Frame
  • Connection Type: Feed-Thru
  • Mounting Mode: Unit Mount Lug
  • Suitable for Reverse-Fed Applications
  • Can Be Used for 2-Pole Applications
  • Control Type: Toggle

Physical Specifications

  • Dimensions (H × W × D): 7.52 × 4.09 × 3.39 Inches
  • Weight: 5.29 lbs

Electrical Connections

  • Line Connection: Lugs Line
  • Load Connection: Lugs Load
  • Wire Size Range: AWG 3/0 to 350 kcmil Aluminum/Copper

Standards and Certifications

  • UL Listed
  • CSA Approved

Features

  • PowerPact molded case circuit breaker
  • MicroLogic 3.2 S electronic trip unit
  • Solid-state protection technology
  • Long-Time, Short-Time, and Instantaneous trip functions
  • High interrupting capacity performance
  • Feed-thru design with line and load lug terminals
  • Suitable for reverse-fed installations
  • Can be configured for 2-pole applications
  • Non-interchangeable electronic trip unit
  • Enhanced selective coordination and system protection
  • Designed for commercial and industrial power distribution systems
  • Manufactured by Schneider Electric / Square D for long-term reliability and performance
