Square D LC1D25G7 IEC Contactor – 3 Pole – 25A (AC-3) / 40A (AC-1) – 120V AC Coil – TeSys Deca Series – DIN Rail/Panel Mount – Motor Starter Contactor

In stock
SKU: LC1D25G7 GTIN/UPC: 38911034973
$102.20
CONDITION
Need Reconditioned? Get Price by Calling
Call Us
Secure transaction
FREE & fast shipping on orders over $149
1 year warranty
30 day returns

Ask an expert

Email 866-972-6370

The Schneider Electric LC1D25G7 is a 3-phase IEC-rated magnetic contactor from the TeSys Deca (LC1D) series, designed for reliable motor control and industrial load switching. It is commonly used in motor starters, HVAC systems, pumps, compressors, and industrial automation panels where medium-duty motor switching and long electrical life are required.

Electrical Ratings

  • Contact Current Rating (AC-3): 25 A
  • AC-1 Rated Current: 40 A
  • Control Coil Voltage: 120 V AC (50/60 Hz)
  • Voltage Rating: up to 600 V AC
  • Motor Power Rating:
    • 7.5 HP at 230 V (3-phase)
    • 15 HP at 480 V (3-phase)
    • 20 HP at 600 V (3-phase)
  • Frequency: 50/60 Hz
  • Utilization Category: AC-3 / AC-1

Configuration and Function

  • Device Type: IEC Motor Contactor
  • Series: TeSys Deca (LC1D Series)
  • Poles: 3 Pole (3 NO main contacts)
  • Auxiliary Contacts: 1 NO + 1 NC (built-in standard configuration)
  • Primary Function: Motor control and power switching
  • Operation: Electromagnetic coil-driven switching

Mechanical and Physical Characteristics

  • Mounting Type: DIN Rail / Panel Mount
  • Terminal Type: Screw clamp terminals
  • Compact 45 mm TeSys D frame design
  • Enclosure Protection: IP2X (front face)
  • Operating Temperature Range: -5 °C to 60 °C
  • High mechanical durability for industrial cycling

Standards and Certifications

  • IEC 60947-4-1 compliant
  • UL / CSA / CE certified (depending on configuration)
  • RoHS compliant design
  • UNSPSC: 39121500

Features

  • Heavy-duty 25A motor switching capability (AC-3 duty)
  • 120V AC coil for standard industrial control circuits
  • Built-in 1NO + 1NC auxiliary contacts for control integration
  • Compact modular design for control panel space savings
  • Compatible with TeSys overload relays for motor protection
  • Suitable for HVAC, pumps, compressors, and automation systems
  • High electrical and mechanical lifespan
  • Part of Schneider Electric global TeSys Deca system
  • Type IEC Contactor
  • Vendor Square D
  • Brand Square D
