Square D LRD3365 Thermal Overload Relay – 80–104A – TeSys Deca Series – Class 10 – Motor Protection Relay for LC1D80/LC1D95 Contactors

The Square D / Schneider Electric LRD3365 is a thermal overload relay from the TeSys Deca (LRD) series designed for reliable protection of large three-phase motors. It is used with LC1D80 and LC1D95 contactors to protect against overload, phase loss, and stalled rotor conditions in demanding industrial motor applications.

Electrical Ratings

• Current Setting Range: 80–104 A
• Phase: 3 Phase
• Poles: 3 Pole (thermal sensing elements)
• Protection Type: Thermal overload protection
• Trip Class: Class 10 (fast motor protection, trips within ~10 seconds under overload conditions)
• Phase Loss Sensitivity: Yes
• Application Type: Motor overload and protection relay

Configuration and Function

• Device Type: Thermal Overload Relay
• Series: TeSys Deca (LRD Series)
• Primary Function: Motor protection (overload, phase failure, stall protection)
• Reset Function: Manual or Automatic reset selectable
• Trip Mechanism: Thermal bimetallic system
• Test Function: Built-in test/reset function
• Trip Indication: Mechanical trip indicator

Compatibility

• Suitable For Use With:
  • LC1D80 contactors
  • LC1D95 contactors
• System Type: Motor starter assembly (contactor + overload relay)
• Installation: Direct mounting under compatible LC1D contactors

Mechanical and Physical Characteristics

• Mounting Type: DIN rail or plate mount (system dependent)
• Terminal Type: Screw clamp terminals
• Compact modular design for control panels
• Heavy-duty industrial construction for high-current applications
• Designed for long service life in harsh environments
• Operating Temperature Range: typically -20 °C to 60 °C

Contacts and Control

• Auxiliary Contacts: 1 NO + 1 NC
• Contact Function: Trip signaling and interlock control
• Reset Options: Manual / Automatic selectable
• Built-in Test Function: Yes
• Mechanical trip indication included

Standards and Certifications

• IEC 60947-4-1 compliant
• UL / CSA / CCC / EAC certified
• ATEX certified (where applicable)
• Marine approvals: DNV-GL, BV, RINA, LROS
• UKCA compliant
• RoHS / REACh compliant
• Manufacturer: Schneider Electric / Square D
• Series: TeSys Deca
• MPN: LRD3365

Features

• Adjustable 80–104A overload protection range
• Designed for high-power industrial motors
• Class 10 fast tripping for sensitive motor protection
• Phase loss detection for enhanced motor safety
• Compatible with LC1D80 and LC1D95 contactors
• 1NO + 1NC auxiliary contacts for control systems
• Direct mounting for compact motor starter assembly
