Square D PEF361600LSG 1600A 3-Pole 100 kA @ 480 VAC - 600V Circuit Breaker LSIG • | Micrologic Electronic Trip

The Square D PEF361600LSG is a high-performance molded case circuit breaker engineered for heavy industrial and commercial power systems.

Electrical & Performance Ratings

• Continuous Current Rating: 1600 A

• Poles / Phase: 3-Pole, 3-Phase

• Voltage Class: up to 600 VAC

• Interrupting Rating (AIC):
    • 100 kA @ 480 VAC
    • 125 kA @ 240 VAC
    • 65 kA @ 600 VAC

• Frequency: 50/60 Hz

• Frame / Family: PE Frame, Type PEF

• Trip Unit / Protection: LSIG – Long-time, Short-time, Instantaneous, Ground Fault (Micrologic electronic trip)

• Mounting: Fixed / Bolt-on

• Dimensions (approx): 13.7 in (W) × 10.47 in (D) × 20.06 in (H)

• Approvals: UL / CSA listed

Additional Information

• Catalog / Model Number: PEF361600LSG

• Alternative Identifiers: sometimes listed as PEF361600LSGPL / PEF361600LSG

• Shipping: typically ships via UPS Ground / freight

• Package Size (approx): 25 in × 25 in × 25 in, ~80 lb shipping weight

Applications

• Main service disconnects

• Large feeder protection

• Switchgear and panelboards requiring advanced LSIG protection
