Square D QE2200VH – 200A 2-Pole 240V Plug-In Thermal Magnetic Circuit Breaker | 22kA @ 240V

Product Description

The Square D QE2200VH is a 200 Amp, 2-pole plug-in molded case circuit breaker designed for use in compatible Square D QE Series panelboards and Meter-Pak™ metering equipment. This breaker features a thermal magnetic trip unit that provides dependable overload and short-circuit protection for commercial and industrial electrical distribution systems.

With a 22kA interrupting rating at 240VAC, the "VH" (Very High Interrupting) version is ideal for applications requiring a higher fault current rating than standard QE breakers. Its plug-in design allows for quick installation while maintaining the reliability and performance expected from Square D products

Key Features

• Genuine Square D / Schneider Electric Circuit Breaker
• Catalog Number: QE2200VH
• QE Series
• 200 Amp Rating
• 2-Pole Configuration
• 120/240VAC
• Thermal Magnetic Trip Unit
• Plug-In Mounting
• 22kA Interrupting Rating @ 240VAC
• "VH" (Very High Interrupting Capacity) Design
• UL Listed
• Designed for QE Series Panelboards and Meter-Pak Equipment

Technical Specifications

Manufacturer: Square D by Schneider Electric

Catalog Number: QE2200VH

Series: QE

Breaker Type: Thermal Magnetic Molded Case Circuit Breaker

Poles: 2

Amperage: 200A

Voltage Rating: 120/240VAC

Phase: Single Phase

Frequency: 50/60 Hz

Interrupting Rating:

• 22kA @ 120/240VAC
• 22kA @ 240VAC

• Trip Unit: Thermal Magnetic

  Trip Functions:

  • Long-Time (Thermal)
  • Instantaneous (Magnetic)

  Connection Type: Plug-In

  Mounting Style: Plug-In

  Frame Type: QE

  Protection Type: Thermal Magnetic

  Standards: UL Listed, CSA Certified

  Operating Temperature: 40°C Maximum

  Approximate Weight: 1 lb

Compatible Equipment

Compatible with Square D equipment designed for QE Series plug-in circuit breakers, including many:

• Square D QE Series Panelboards
• Square D Meter-Pak™ Meter Centers
• Compatible Schneider Electric Distribution Equipment utilizing QE breakers

Always verify panel compatibility before installation.

Product Data

Brand: Square D by Schneider Electric

Model: QE2200VH

UPC / GTIN: 785901019213
