Square D QO120PAFGF 20A 1-Pole Dual-Function AFCI/GFCI Circuit Breaker – Plug-On Neutral

The Square D QO120PAFGF is a 20-amp, single-pole dual-function breaker manufactured by Schneider Electric under the Square D QO series. It provides combination Arc-Fault (AFCI) and Ground-Fault (GFCI) protection, helping safeguard circuits against both arc-fault hazards and ground-fault shock risks. The plug-on neutral design simplifies installation in compatible QO load centers.

Voltage and Ratings

• Voltage Rating: 120 Volts AC
• Amperage Rating: 20 Amp
• Poles: 1-Pole
• Interrupt Rating: 10 kA

Key Specifications

• Breaker Type: Combination AFCI/GFCI (Dual Function)
• Mounting Type: Plug-In
• Neutral Connection: Plug-On Neutral
• Ground-Fault Protection: Class A, 6 mA
• Compatibility: Square D QO plug-on-neutral load centers

Technical Specifications

• Wire Size: AWG 14 to AWG 8 (Copper or Aluminum)
• Tightening Torque: 35.4 lbf-in (4 N·m)
• Dimensions (H × W × D): 2.72 × 0.75 × 4.10 in
• Weight: 0.351 lb
• Certifications: UL Listed

Product Data

• Brand: Square D
• Manufacturer: Schneider Electric
• Model Number: QO120PAFGF
• UPC: 785901779278
• Product Range: QO
• Application: Residential branch circuits requiring both arc-fault and ground-fault protection
