Square D QO270VH Miniature Circuit Breaker – 70A – 2 Pole – 120/240V – Plug-In – VisiTrip – QO Series

The Square D QO270VH is a QO-series plug-in miniature circuit breaker designed for reliable overcurrent protection in QO load centers, NQ/NQOD panelboards, and OEM distribution systems. It provides thermal magnetic protection for overload and short-circuit conditions and includes a VisiTrip indicator for fast visual identification of a tripped breaker. This model is commonly used in HVAC, refrigeration, heating, and general power distribution applications requiring dependable circuit protection and clear fault indication.

Electrical Ratings

• Current Rating: 70 A
• Voltage Rating: 120/240 VAC
• Frequency: 50/60 Hz
• Phase: 1 Phase
• Poles: 2 Pole
• Interrupting Rating: 22 kA @ 120/240 VAC

Protection and Function

• Trip Technology: Thermal Magnetic
• Trip Function: Common Trip (Overload + Short-Circuit Protection)
• Protection Type: Branch circuit protection
• Application: HVAC, heating, air conditioning, refrigeration, and general distribution circuits

Configuration and Function

• Series: QO Series (Square D / Schneider Electric)
• Model: QO-VH
• Catalog Number: QO270VH
• Frame Type: QO Miniature Frame
• Mounting Style: Plug-On
• Terminal Type: Box Lug
• Compatibility: QO Load Centers, NQ/NQOD Panelboards, OEM interiors

Mechanical and Physical Characteristics

• Compact molded breaker body
• Plug-on installation for fast panel integration
• Integrated VisiTrip fault indicator for quick troubleshooting
• Box lug terminals for secure conductor termination
• Designed for standard branch circuit distribution
• Space-efficient QO-frame construction

Standards and Certifications

• UL Listed
• CSA Certified
• Manufactured by Schneider Electric / Square D
• Designed for North American electrical distribution standards

Features

• Thermal magnetic protection for overload and short-circuit faults
• VisiTrip indicator for rapid visual fault detection
• Plug-on mounting for QO compatibility
• Compact design optimized for panelboard space efficiency
• Suitable for HVAC and refrigeration systems
• Reliable performance in QO and NQ/NQOD systems
• Clear trip indication improves maintenance and troubleshooting speed
