Square D QO3100VH Miniature Circuit Breaker – 100A – 3 Pole – 240V – Plug-In – VisiTrip – QO Series

The Square D QO3100VH is a QO-series three-pole miniature circuit breaker designed for reliable overcurrent protection in residential, commercial, and light industrial 240VAC distribution systems. It provides thermal magnetic protection for overload and short-circuit conditions and includes a VisiTrip indicator for fast visual identification of a tripped breaker. This model is commonly used in QO load centers, NQ/NQOD panelboards, and OEM distribution equipment where high-capacity three-phase protection is required.

Electrical Ratings

• Current Rating: 100 A
• Voltage Rating: 240 VAC
• Frequency: 50/60 Hz
• Phase: 3 Phase
• Poles: 3 Pole
• Interrupting Rating: 22 kA @ 240 VAC

Protection and Function

• Trip Technology: Thermal Magnetic
• Trip Function: Common Trip (Overload + Short-Circuit Protection)
• Protection Type: Branch circuit protection
• Application: Three-phase power distribution, motors, HVAC, and panelboard feeder circuits

Configuration and Function

• Series: QO Series (Square D / Schneider Electric)
• Model: QO-VH
• Catalog Number: QO3100VH
• Frame Type: QO Miniature Frame
• Mounting Style: Plug-On
• Terminal Type: Box Lug
• Compatibility: QO Load Centers, NQ/NQOD Panelboards, OEM interiors / Speed-D switchboards

Mechanical and Physical Characteristics

• Compact molded breaker housing
• Plug-on installation for QO system compatibility
• Integrated VisiTrip fault indicator for quick troubleshooting
• Box lug terminals for secure conductor termination
• Designed for standard three-phase branch circuit distribution
• Wire range: 4 AWG to 2/0 AWG (Aluminum/Copper)
• Space-efficient QO-frame construction

Standards and Certifications

• UL Listed
• CSA Certified
• Manufactured by Schneider Electric / Square D
• Designed for North American electrical distribution standards
